13-INCH COLOR E-PAPER DISPLAY
- 13" EMDX Series Color E-Paper Smart Signage: Samsung's 13" Color E-Paper EMDX Series delivers paper-like picture quality, digitizing the traditional paper experience. | Ultra-thin depth of 0.7 inches (17.9mm) for an aesthetically pleasing design in any environment. | Dedicated battery with USB Type-C support in an easy-to-move, lightweight frame for versatile placement. | Dedicated Samsung E-Paper App enables easy control via Android and iOS devices.* | * Samsung E-Paper App requires mobile device running Android 10 or later or iOS 15 or later. Actual user experience and UI may differ and are subject to change without notice.
| General Information | |
|---|---|
| Category | Flat panel displays |
| Description | 13-INCH COLOR E-PAPER DISPLAY |
| Manufacturer | Samsung |
| MSRP | $875.00 |
| UNSPSC | 43211902 |
| Main Specifications | |
| Height | 2.50 |
| Length | 17.90 |
| UPC | 0198957269011 |
| Width | 63.66 |
| Connections | |
| Connector Type |
|
| Dimensions & Weight (JTFpping) | |
| Depth (JTFpping) | 6 cm |
| Height (JTFpping) | 29.5 cm |
| Weight (JTFpping) | 1.8 kg |
| Width (JTFpping) | 45.5 cm |
| Display | |
| Additional Features | Security lock slot (cable lock sold separately) |
| Color Support | 54600 colors |
| Commercial Features | Samsung VXT CMS, Custom App (TEP) compatible, Samsung E-Paper App |
| Image Aspect Ratio | 4:3 |
| Operation Hours / Days | 24 / 7 |
| Pixel Pitch | 0.169 mm |
| Resolution | 1600 x 1200 |
| Viewing Angle | 178° |
| Viewing Angle (Vertical) | 178° |
| Environmental Parameters | |
| Humidity Range Operating | 30 - 70% (non-condensing) |
| Max Operating Temperature | 40 °C |
| Min Operating Temperature | 0 °C |
| General | |
| Commercial Use | Yes - digital signage |
| Depth | 1.79 cm |
| Design | Ultra Thin Design |
| Diagonal Class | 13" |
| Diagonal Size | 13.3" |
| Dimensions | Without stand |
| Enclosure Color | Gray white |
| Height | 23.76 cm |
| Modes | Portrait mode, landscape mode |
| Operating System | Tizen OS 8.0 |
| PC Interface | USB-C |
| Picture Enhancements | Color Imaging Algorithm |
| Platform | Tizen OS |
| Product Type | E-Paper display - E Ink Spectra 6 |
| Series | EMDX series |
| TV Tuner | No tuner |
| TV Tuner Presence | No |
| Weight | 900 g |
| Width | 30.52 cm |
| Manufacturer Warranty | |
| Service & Support |
|
| Media Player | |
| Configuration | 8 GB |
| USB Port | Yes |
| USB Ports Qty | 2 |
| Miscellaneous | |
| Cables Included | USB-C charge cable |
| Compliant Standards | EMC Class A, IP5X, Safety 60950-1, Safety 62368-1, UL |
| Included Accessories | 25 W USB-C power adapter, 2 rear mounts, 2 brackets |
| Security Slot Type | Kensington security slot |
| Network & Internet Multimedia | |
| Bluetooth Version | Bluetooth 5.0 |
| Connectivity | Wi-Fi, LAN, Bluetooth |
| Wi-Fi Protocol | 802.11ac |
| Power | |
| Battery | Battery - lithium ion |
| Capacity | 4600 mAh |
| Input Voltage | AC 100-240 V (50/60 Hz) |
| Power Device | Power adapter + battery |
| Power Over Ethernet (PoE) Support | Yes |
| Stands & Mounts | |
| Flat Panel Mount Interface | 100 x 100 mm |
| Stand | Included |
| Stand Design | Kickstand |
| VESA Compatibility | Yes |
