SMART-UPS 500VA LCD 100V

Be the first to review this product

Availability: Out of stock

SKU

SMT500J

UPC Code

731304290902

Request a Quote

Questions before you move forward?

Chat with a JTF expert in Springfield, VA.

Click and connect instantly.

secure transaction

Details

This APC Smart-UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. The 500VA line interactive tower UPS provides pure sine wave power to support critical electronics during power disruptions. It comes with NEMA 5-15P input and 6 NEMA 5-15R outlets. It has a SmartSlot for optional Network Management Card that enables graceful shutdown of physical servers, virtual machines & HCI Clusters via PowerChute Network Shutdown. The UPS can connect to EcoStruxure IT or third-party centralized management platforms. It provides surge protection against lightning strikes, power sags, brownouts and surges. The SMT UPS has a 2-year warranty and comes with a built-in lead-acid battery. It is compatible with a dedicated user-replaceable battery, and the APC replacement battery cartridge helps restore UPS performance to the original specifications.

Specifications

General Information
Category	Power conditioning equipment
Description	SMART-UPS 500VA LCD 100V
Manufacturer	APC by Schneider Electric
MSRP	$1,150.00
UNSPSC	39121000
Main Specifications
Dimensions & Weight / Depth	35.9 cm
Dimensions & Weight / Height	16.7 cm
Dimensions & Weight / Weight	12.6 kg
Dimensions & Weight / Width	14 cm
Header / Brand	APC
Header / Country Kits	Japan
Miscellaneous / Product Color	Black
Networking / Remote Management Interface	RS-232 USB
Packaged Quantity	1
Power Device / Form Factor	External
Power Device / Output Connector Qty	6
Power Device / Power Capacity (VA)	500 VA
Power Device / UPS Technology	Line interactive
Power Device / Voltage Required	AC 100 V
Product Type	UPS
Service & Support / Type	2-year warranty
Battery
Quantity	1
Recharge Time	4 hours
Run Time (Up To)	9 min at full load 28 min at half load
Technology	Lead acid
Dimensions & Weight
Depth	35.9 cm
Height	16.7 cm
Weight	12.6 kg
Width	14 cm
Dimensions & Weight (JTFpping)
JTFpping Depth	49.9 cm
JTFpping Height	30.1 cm
JTFpping Weight	14.23 kg
JTFpping Width	27.8 cm
Environmental Parameters
Humidity Range Operating	0 - 95% (non-condensing)
Max Operating Temperature	40 °C
Min Operating Temperature	0 °C
Sound Emission	55 dBA
Expansion / Connectivity
Expansion Slots	1 (total) / 1 (free) x SmartSlot
Interfaces	1 x management (USB) - 4 pin USB Type B 1 x management (RS-232)
General
Battery Enclosure Type	Internal
Color	Black
Device Type	UPS - external
Localization	Japan
Manufacturer Warranty
Service & Support	Limited warranty - 2 years
Miscellaneous
Cables Included	Serial cable - external Power cable 1.83 m
Compliant Standards	UL 1449, UL 1778, VCCI Class A ITE, RoHS Exemption 7b, REACH
Features	Audible alarm, LCD display, Automatic Voltage Regulation (AVR), LED indicators, noise filtering, automatic self-test, predicitive failure notification, hot-swappable batteries
Networking
Remote Management Interface	RS-232, USB
Power Device
Circuit Protection	Circuit breaker
Frequency Provided	47 - 53 / 57 - 63 Hz
Frequency Required	50/60 Hz
Input Connectors	1 x power NEMA 5-15
Input Voltage	AC 100 V
Input Voltage Range	AC 70 - 125 V
Input Voltage Range (Adjustable)	AC 80 - 123 V
Output Voltage	AC 100 V ± 5% - 47 - 53 / 57 - 63 Hz
Output Waveform	Sinewave
Power Capacity	360 watt / 500 VA
Power Output Connectors Details	6 x power NEMA 5-15
Surge Energy Rating	540 joules
Surge Suppression	Yes
UPS Technology	Line interactive
Sustainability Information
Packaging Recycled Content	Made of recycled cardboard
