Sharp MX-C304W Desktop Color Workgroup Document System
- Copier, Printer, Scanner, Fax
- 30 PPM B&W / Color
- Control panel display 7.0-inch colour LCD touchscreen
- 500 GB HDD with document filing system
- Paper capacity (Std – Max) Sheets 300 - 2,700
- Modem speed (bps) 33,600 – 2,400 with automatic fallback
- Continuous copies (Max) 9,999
- Memory (GB) Copier/Printer (shared) 5 HDD*4 500
- Dimensions (in) (W x D x H) 19.34 x 134.18 x 22.25
- Weight (lb) 83.78
Sharp MX-C304W Desktop Color Workgroup Document System
Engine speed (ppm/cpm) (Max) A4 MX-C304W 30 Control panel display 7.0-inch colour LCD touchscreen Paper size (Min – Max) A6 – A4 Paper weight (g/m2) Drawer 1 60 - 105
Drawers 2 – 5 55 - 220
Multi-bypass 55 - 220Paper capacity (Std – Max) Sheets 300 - 2,700
Drawers 1 - 5 (plus bypass tray)Warm-up time (seconds) 47 Memory (GB) Copier/Printer (shared) 5
HDD*4 500Power requirements Rated local AC voltage ±10%, 50/60 Hz Power consumption (kW) (Max) 1.84 (220 to 240V) Dimensions (in) (W x D x H) 19.34 x 134.18 x 22.25 Weight (lb) (approx.) 83.78 Copier Original paper size (Max) A4 First copy time (seconds) Colour 6.7
B/W 5.5Continuous copies (Max) 9,999 Print resolution (dpi) Scan 600 x 600, 600 x 400 Gradation levels 256 Zoom range (%) 25 – 400, (25 – 200 using RSPF/DSPF) in 1% increments Preset copy ratios (Metric) 10 ratios (5R/5E) Network Printer Resolution (dpi) 600 x 600, 9600 (equivalent) x 600 Interface USB 2.0, 10Base-T/100Base-TX/1000Base-T Supported OS 2008, 2008R2, 2012, 2012R2, 2016, Windows® 7, 8.1, 10
Mac OS X 10.6, 10.7, 10.8, 10.9, 10.10, 10.11, 10.12, 10.13Network protocols TCP/IP Printing protocols LPR, Raw TCP (port 9100), POP3 (e-mail printing), HTTP, FTP for downloading print files, IPP, SMB, WSD PDL (Std) PCL 6, Genuine Adobe® PostScript®3TM Available fonts 80 fonts for PCL, 139 fonts for Adobe PostScript 3TM Network Scanner Scan method Push scan (via control panel)
Pull scan (TWAIN-compliant application)Scan speed (ipm) One-sided 70, Two-sided 110 Resolution (dpi) (Max) Push scan 100, 150, 200, 300, 400, 600
Pull scan 75, 100, 150, 200, 300, 400, 600
50 to 9,600 dpi via user settingFile formats TIFF, PDF, PDF/A-1a*9, PDF/A-1b, encrypted PDF, compact
PDF*10 *11, JPEG*10, XPS, searchable PDF*9, OOXML*9 (docx, xlxs, pptx), text (TXT)*9, rich text (RTF)*9Scan destinations Scan to e-mail, desktop*12, FTP server, network folder
(SMB), USB memoryScanner utilities Sharpdesk Document Filing Document filing capacity Pages - Main & custom folders 20,000 3,000,
Files - Quick file folder 10,000 1,000Stored jobs Copy, print, scan, fax transmission Storage folders Quick file folder, main folder, custom folder (max. 1,000) Confidential storage Password protection (for main & custom folders) Fax Compression method MH/MR/MMR/JBIG Communication protocol Super G3 Transmission time (seconds) 2 Modem speed (bps) 33,600 – 2,400 with automatic fallback Recording width A4 – A5 Memory (GB) 1 (built-in) Wireless LAN Compliant regulation IEEE802.11n/g/b Access mode Infrastructure mode, Software AP mode Security WEP, WPA/WPA2-mixed PSK, WPA/WPA2-mixed EAP*16,WPA2 PSK, WPA2 EAP*16
Onsite Service
Following your purchase, JTF will assign an authorized service partner in your area to your account. Your service calls are processed and dispatched in just minutes after they are received, thus minimizing your downtimes. All service partners are authorized, factory trained and 100% endorsed by JTF Network Partners, with over 600 service dealers nationwide*
Same Day Onsite Service:
Same Day Service is provided at your business or home during the contracted Maintenance period.
Exceptions:
1) Your offices are 40 miles away from the closest service providers.
2) Service in HI, AK & PR.
Convenient Assistance:
Having device issues?
Experts are here 8am -6pm weekly to help solve your technical problems.
Fast, free replacements:
If we can’t fix your printer, we’ll try to replace it by the next business day.
No hidden fees:
Parts and labor, replacements, even return shipping — it’s all covered by your JTF Warranty.
Optional extra coverage:
Additional coverage to include supplies are available for purchase.
No Expert Install
$199.00 Expert Install
Installation Service for equipment includes the following:
JTF will schedule an appointment with one person per site. Unless otherwise requested and/or scheduled, the standard practice is to start all installation services within one week the delivery of the hardware to the customer’s location.
Unpacking: JTF will inventory the shipment against the packing list, unpack and install all delivered products.
Setup/Installation: JTF will physically assemble, connect peripherals, network cables, and power cords that were purchased from JTF.
a. This service provides installation of drivers on a single PC workstation (not server), network setup, including the programming of the IP address and network settings and verification of the network functionality, wireless connection setup and verification of the functionality over the Internet.
b. For configuration networking, the Customer can choose between automatic configuration using BOOTCP or Dynamic Host Configuration Protocol (DHCP), or manual configuration with IP address, default gateway, and subnet mask.
c. For multifunction products, the service provides setup of the ‘send to email configuration’ and configuration of the SMTP or LDAP.
d. This service provides the Customer-identified key operator with a basic overview on how to install consumables, plus explanations of basic features and functionality such as drivers, control panel features, embedded Web server, and alerts.
