Lenovo ThinkCentre M90q Gen 5 12TH
The Lenovo ThinkCentre M90q Gen 5 is designed for efficiency and compactness, offering a powerful computing experience in an ultra-small form factor. This personal computer features an Intel Core i7 processor with 20 cores and a clock speed of 2.1 GHz, ensuring smooth multitasking and efficient operation for any workload. With DDR5 SDRAM for rapid data processing and a built-in trusted platform module for enhanced security, this device is built to handle demanding tasks securely. Equipped with PCI Express 4.0 x4 SSD storage, the system delivers quick data access and storage performance. The connectivity options are plentiful, featuring multiple USB ports, HDMI, and DisplayPort interfaces, enabling integration with peripherals. EPEAT Gold and ENERGY STAR certifications reflect its environmentally conscious design, allowing users to operate sustainably while meeting their performance needs.







- Performance-Driven, Productivity Perfected: Powered by a powerful processor, the ThinkCentre M90q Gen 5 Tiny PC delivers enterprise-class performance, security, manageability, and reliability. Designed for businesses of all sizes, it maximizes productivity, creativity, and digital collaboration with generous memory, storage, and Wi-Fi.
- Workspace Efficiency Redefined: Connect multiple devices via the port hub and customize it with additional expansion slots. Easily charge your smartphone via the USB PowerShare port, even when your computer is off. Support for four independent displays lets you multitask effortlessly. Nothing can stop you.
- Device Convenience Reimagined: With a keyboard shortcut to turn on the desktop, and a quick boot-up process via the Thunder Boot feature, this ThinkCentre PC reflects ease of convenience, making it the perfect choice for modern workspaces. Plus, with Modern Standby, your system remains up-to-date even during sleep mode, and it wakes and connects instantly.
- Ultimate PC Security Enabled: ThinkJTFeld security encrypts data with a Trusted Platform Module (dTPM), and BIOS recovery restores your system to its previous settings. Physically protect your PC and choose a platform with multi-layered protection, including against cyberattacks and ransomware.
- Effortless Upgrades, Easy Maintenance: Along with a sleek design, the ThinkCentre M90q Gen 5 Tiny desktop is also ready for toolless upgrades, saving IT valuable time. The optional removable easy-to-clean dust JTFeld assists with upkeep to extend the lifecycle. Plus, an AI-driven fan prevents overheating issues — keeping the system cool and efficient for all-day-long operations.
- Future Forward, Future Ready: The M90q Gen 5's case is made primarily from recycled acrylonitrile butadiene styrene plastic. The packaging is made from recycled industrial materials, while the case and cooler bag are made from marine-sourced plastics. It's also FSC (Forest StewardJTFp Council) certified. Additionally, the ENERGY STAR® 8.0 and TCO 9.0 certifications help reduce energy costs.
| General Information | |
|---|---|
| Category | Desktop computers |
| Description | Lenovo ThinkCentre M90q Gen 5 12TH - Tiny Core i7 i7-14700 / up to 5.4 GHz - vPro Enterprise - RAM 32 GB - SSD 512 GB - UHD Graphics 770 - Gigabit Ethernet, IEEE 802.11ax (Wi-Fi 6E), Bluetooth 5.3 - Win 11 Pro - monitor: none - keyboard: English - black - Lenovo TopSeller |
| Manufacturer | Lenovo |
| MSRP | $2,339.00 |
| UNSPSC | 43211507 |
| Main Specifications | |
| Chassis / Form Factor | Ultra small form factor |
| Dimensions & Weight / Depth | 18.29 cm |
| Dimensions & Weight / Height | 3.65 cm |
| Dimensions & Weight / Weight | 1.25 kg |
| Dimensions & Weight / Width | 17.9 cm |
| Display / Type | None. |
| Hard Drive / Capacity | 512 GB |
| Hard Drive / Interface | PCI Express 4.0 x4 |
| Hard Drive / Interface Type | PCI Express 4.0 x4 |
| Header / Brand | Lenovo |
| Header / Country Kits | United States |
| Header / Localization | English |
| Mainboard / Chipset Type | Intel Q670 |
| Miscellaneous / Product Color | Black |
| Networking / Data Link Protocol |
|
| Networking / Wireless LAN Supported | Yes |
| Networking / Wireless Protocol |
|
| Optical Storage / Drive Type | No optical drive |
| Optical Storage / Type | None |
| OS Provided / Type | Windows 11 Pro |
| Packaged Quantity | 1 |
| Processor / Clock Speed | 2.1 GHz |
| Processor / Generation | 14 |
| Processor / Manufacturer | Intel |
| Processor / Number of Cores | 20-core |
| Processor / Processor Number | I7-14700 |
| Processor / Type | Core i7 |
| RAM / Form Factor | SO-DIMM 262-pin |
| RAM / Technology | DDR5 SDRAM |
| Service & Support / Type | 3-year warranty |
| System / Hard Drive Capacity | 512 GB |
| System / Platform Technology | Intel vPro Enterprise |
| System / Type | Personal computer |
| Video Output / Graphics Processor | Intel UHD Graphics 770 |
| Audio Output | |
| Compliant Standards | High Definition Audio |
| Speakers Included | 1 x tweeter |
| Cache Memory | |
| Cache Per Processor | 33 MB |
| Installed Size | 33 MB |
| Dimensions & Weight | |
| Depth | 18.29 cm |
| Height | 3.65 cm |
| Weight | 1.25 kg |
| Width | 17.9 cm |
| Environmental Parameters | |
| Humidity Range Operating | 20 - 80% |
| Max Operating Temperature | 35 °C |
| Min Operating Temperature | 5 °C |
| Expansion / Connectivity | |
| Interfaces |
|
| Slots |
|
| General | |
| Built-in Devices | Speaker |
| Color | Black |
| Embedded Security | Discrete Trusted Platform Module (TPM 2.0) Security Chip |
| Localization | Language: English / region: United States |
| Platform Technology | Intel vPro Enterprise |
| Product Form Factor | Tiny |
| Type | Personal computer |
| Graphics Controller | |
| Graphics Processor | Intel UHD Graphics 770 shared video memory (UMA) |
| Hard Drive | |
| Capacity | 1 x 512 GB |
| Features | TCG Opal Encryption 2.0, NVM Express (NVMe) |
| Interface Type | PCI Express 4.0 x4 |
| Type | SSD - M.2 2280 |
| Input Device | |
| Type | Mouse, keyboard |
| Keyboard | |
| Interface | USB |
| Keyboard Name | Lenovo Traditional Keyboard |
| Localization & Layout | English |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years - on-site |
| Miscellaneous | |
| Compliant Standards | RoHS, FIPS 140-2, Energy-Related Products (ErP) Lot 3, TCG Certified |
| Included Accessories | Vertical stand |
| Manufacturer Selling Program | Lenovo TopSeller |
| Security Slot Type | Kensington security slot |
| Theft/Intrusion Protection | Security lock slot (cable lock sold separately), chassis intrusion switch |
| Monitor | |
| Monitor Type | None. |
| Mouse | |
| Interface | USB |
| Mouse Name | Lenovo Calliope Mouse |
| Networking | |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6E), Bluetooth 5.3 |
| Features | Dual stream (2x2) |
| Wireless LAN Supported | Yes |
| Wireless NIC | Intel Wi-Fi 6E AX 211 |
| Operating System / Software | |
| OS Provided | Windows 11 Pro English |
| Optical Storage | |
| Type | No optical drive |
| Power | |
| Device Type | Power adapter |
| Efficiency | 89% |
| Power Provided | 230 watt |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Processor / Chipset | |
| Chipset Type | Intel Q670 |
| Clock Speed | 2.1 GHz (P-core) / 1.5 GHz (E-core) |
| CPU | Intel Core i7 (14th Gen) i7-14700 |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
| Max Turbo Speed | 5.4 GHz (P-core) / 4.2 GHz (E-core) |
| Number of Cores | 20-core |
| RAM | |
| Configuration Features | 1 x 32 GB |
| Features | Dual channel memory architecture |
| Form Factor | SO-DIMM 262-pin |
| Installed Size | 32 GB (installed) / 64 GB (max) |
| Rated Memory Speed | 5200 MHz |
| Slots | 2 (total) / 1 (empty) |
| Technology | DDR5 SDRAM |
| Sustainability Information | |
| ENERGY STAR Certified | Yes |
| ENERGY STAR Version | 8.0 |
| EPEAT Compliant | EPEAT Gold |
| TCO Certified | TCO Certified Desktops 9 |
