Lenovo ThinkCentre M70q Gen 6 13A4

Availability: Out of stock
SKU
13A4002CUS
UPC Code
199271049426
Questions before you move forward?

Chat with a JTF expert in Springfield, VA.

Click and connect instantly.

secure transactionsecure transaction
The Lenovo ThinkCentre M70q Gen 6 is an ultra small form factor personal computer that combines performance and efficiency for various tasks. Powered by a 20-core Intel Core Ultra 7 processor, it reaches a maximum turbo speed of 5.3 GHz, ensuring quick processing of applications and multitasking capabilities. With DDR5 RAM and a PCI Express NVMe SSD, users experience rapid data access and storage performance, enhancing productivity. The device is designed for energy efficiency, certified by ENERGY STAR version 9.0, making it a choice for environmentally conscious consumers. Connectivity is essential for any modern workstation, and this model does not disappoint. It features multiple ports including USB-C 3.2 Gen 2, HDMI, and DisplayPort 1.4a, allowing for integration with various peripherals. The built-in speaker adds convenience for audio playback, while the included Lenovo Traditional Keyboard and Lenovo Calliope Mouse offer a computing experience. The compact size of the M70q makes it easy to fit into tight spaces without compromising performance or features.
Product image 13A4002CUS
Product image 13A4002CUS
Product image 13A4002CUS
Product image 13A4002CUS
Product image 13A4002CUS
Product image 13A4002CUS
Product image 13A4002CUS
  • Tiny PC Driving Business Productivity: Lenovo ThinkCentre M70q Gen 6 (Intel) Tiny PC | Equipped with powerful processors and technology for security and IT management | AI-enabled performance, a durable design, and the ability to connect up to 4 monitors | Additional I/O ports and expandable storage for increased business productivity
General Information
CategoryDesktop computers
DescriptionLenovo ThinkCentre M70q Gen 6 13A4 - AI PC - tiny Core Ultra 7 265T / up to 5.3 GHz - vPro Enterprise - RAM 16 GB - SSD 256 GB - TCG Opal Encryption, NVMe - Intel Graphics - Gigabit Ethernet, IEEE 802.11ax (Wi-Fi 6E), Bluetooth 5.3 - Win 11 Pro - monitor: none - keyboard: English - raven black - Lenovo TopSeller
ManufacturerLenovo
MSRP$1,689.00
UNSPSC43211507
Main Specifications
Chassis / Form FactorUltra small form factor
Dimensions & Weight / Depth18.29 cm
Dimensions & Weight / Height3.65 cm
Dimensions & Weight / Weight1.18 kg
Dimensions & Weight / Width17.9 cm
Display / TypeNone.
Hard Drive / Capacity256 GB
Hard Drive / InterfacePCI Express 4.0 x4
Hard Drive / Interface TypePCI Express 4.0 x4
Header / BrandLenovo
Header / Country KitsUnited States
Header / LocalizationEnglish
Mainboard / Chipset TypeIntel Q870
Miscellaneous / Product ColorBlack
Networking / Data Link Protocol
  • Bluetooth 5.3
  • Ethernet
  • Fast Ethernet
  • Gigabit Ethernet
  • IEEE 802.11a
  • IEEE 802.11ac
  • IEEE 802.11ax (Wi-Fi 6E)
  • IEEE 802.11b
  • IEEE 802.11g
  • IEEE 802.11n
Networking / Wireless LAN SupportedYes
Networking / Wireless Protocol
  • 802.11a/b/g/n/ac/ax (Wi-Fi 6E)
  • Bluetooth 5.3
Optical Storage / Drive TypeNo optical drive
Optical Storage / TypeNone
OS Provided / TypeWindows 11 Pro
Packaged Quantity1
Processor / Clock Speed1.5 GHz
Processor / GenerationSeries 2
Processor / ManufacturerIntel
Processor / Number of Cores20-core
Processor / Processor Number265T
Processor / TypeCore Ultra 7
RAM / Form FactorSO-DIMM 262-pin
RAM / TechnologyDDR5 SDRAM
Service & Support / Type3-year warranty
System / Hard Drive Capacity256 GB
System / Platform TechnologyIntel vPro Enterprise
System / TypePersonal computer
Video Output / Graphics ProcessorIntel Graphics
Audio Output
Compliant StandardsHigh Definition Audio
Cache Memory
Cache Per Processor30 MB
Installed Size30 MB
Dimensions & Weight
Depth18.29 cm
Height3.65 cm
Weight1.18 kg
Width17.9 cm
Dimensions & Weight (JTFpping)
JTFpping Depth48.8 cm
JTFpping Height26.6 cm
JTFpping Weight3.12 kg
JTFpping Width14 cm
Environmental Parameters
Humidity Range Operating20 - 80%
Max Operating Temperature35 °C
Min Operating Temperature5 °C
Expansion / Connectivity
Interfaces
  • 3 x USB 3.2 Gen 2 (1 front, 2 rear)
  • 1 x USB 3.2 Gen 2 (1 in front) (Always On, fast-charging (5V, 2.1A))
  • 1 x USB-C 3.2 Gen 2 (1 in front)
  • 1 x headphones/microphone (1 in front)
  • 1 x USB 3.2 Gen 1 (1 rear) (supports SmartPower On)
  • 1 x USB 3.2 Gen 1 (1 rear)
  • 1 x DisplayPort 1.4a
  • 1 x HDMI
  • 1 x LAN (Gigabit Ethernet) (1 rear)
  • 1 x DisplayPort 1.4
Slots
  • 1 (total) / 0 (free) x M.2 Card (for WLAN)
  • 2 (total) / 1 (free) x M.2 Card (for SSD)
General
AI LevelAI PC
Built-in DevicesSpeaker
ColorRaven black
Embedded SecurityDiscrete Trusted Platform Module (TPM 2.0) Security Chip
LocalizationLanguage: English / region: United States
Platform TechnologyIntel vPro Enterprise
Product Form FactorTiny
TypePersonal computer
Graphics Controller
Graphics ProcessorIntel Graphics shared video memory (UMA) - up to 8 TOPS
Max Monitors Supported3
Video InterfacesHDMI, DisplayPort
Hard Drive
Capacity1 x 256 GB
FeaturesTCG Opal Encryption, NVM Express (NVMe)
Interface TypePCI Express 4.0 x4
TypeSSD - M.2 2280
Input Device
TypeMouse, keyboard
Keyboard
InterfaceUSB
Keyboard NameLenovo Traditional Keyboard
Localization & LayoutEnglish
Manufacturer Warranty
Service & SupportLimited warranty - 3 years - on-site
Miscellaneous
Compliant StandardsRoHS, FIPS 140-2, TCG Certified
Included AccessoriesVertical stand
Manufacturer Selling ProgramLenovo TopSeller
Security Slot TypeKensington security slot
Theft/Intrusion ProtectionSecurity lock slot (cable lock sold separately), chassis intrusion switch
Monitor
Monitor TypeNone.
Mouse
InterfaceUSB
Mouse NameLenovo Calliope Mouse
Networking
Data Link ProtocolEthernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6E), Bluetooth 5.3
Ethernet ControllerIntel I219-LM
FeaturesWake on LAN (WoL), dual stream (2x2)
Interface (Bus) TypeM.2 Card
Wireless LAN SupportedYes
Wireless NICIntel Wi-Fi 6E AX 211
Neural Processor Unit (NPU)
AI Datatype Support on NPUINT8
AI Software Frameworks Supported by NPUDirectML, OpenVINO, WebNN, WindowsML, ONNX RT
Neural Processor Unit (NPU)Intel AI Boost
NPU Performance Up To (TOPS)13 TOPS
Sparsity SupportYes
Total Processor Performance Up To (TOPS)33 TOPS
Windows Studio Effects SupportYes
Operating System / Software
Microsoft CopilotYes
OS ProvidedWindows 11 Pro English
Optical Storage
TypeNo optical drive
Power
Device TypePower adapter
Efficiency90%
Power Provided135 watt
Voltage RequiredAC 100-240 V (50/60 Hz)
Processor / Chipset
Chipset TypeIntel Q870
Clock Speed1.5 GHz (P-core) / 1.2 GHz (E-core)
CPUIntel Core Ultra 7 (Series 2) 265T
CPU Qty1
L2 cache36 MB
Max CPU Qty1
Max Turbo Speed5.3 GHz (P-core) / 4.6 GHz (E-core)
Number of Cores20-core
Processor Main FeaturesIntel Smart Cache
RAM
Configuration Features1 x 16 GB
Effective Memory Speed5600 MT/s
FeaturesDual channel memory architecture
Form FactorSO-DIMM 262-pin
Installed Size16 GB (installed) / 64 GB (max)
Rated Memory Speed5600 MT/s
Slots2 (total) / 1 (empty)
TechnologyDDR5 SDRAM
Sustainability Information
Carbon Footprint253 kg carbon emissions
ENERGY STAR CertifiedYes
ENERGY STAR Version9.0
EPEAT CompliantEPEAT Gold
PAIA Version1.4.6
TCO CertifiedTCO Certified, generation 10, for desktops
Total CF/unit Standard Deviation (kg CO2e)52
