Lenovo ThinkSystem 7500 PRO

Availability: Out of stock
SKU
4XB7A95053
Questions before you move forward?

Chat with a JTF expert in Springfield, VA.

Click and connect instantly.

secure transactionsecure transaction
The Lenovo ThinkSystem 7500 PRO is designed for high-performance environments where reliability and speed are essential. With a robust capacity of 15.36 TB and an internal data rate of 7000 MBps, this solid-state drive ensures quick access to data, making it suitable for enterprise applications and demanding workloads. Its features such as adaptive thermal monitoring and end-to-end data protection contribute to maintaining the integrity and availability of vital data, even in challenging conditions. With an operating temperature range from 0 °C to 70 °C and a storage temperature range of -40 °C to 85 °C, this drive is resilient in various environments, suitable for both data centers and remote locations. Additionally, with a mean time between failures (MTBF) of 2,000,000 hours, it offers longevity over time. Equipped with significant encryption capabilities through self-encrypting drive technology, the Lenovo ThinkSystem 7500 PRO ensures that data remains secure. Features like Secure Boot and Key-Based Firmware Update add layers of protection to the stored information. Furthermore, with performance metrics such as 4KB random read IOPS at 1,100,000 and write IOPS at 250,000, this drive handles intensive workloads effortlessly. The integration of 3D triple-level cell (TLC) NAND technology offers improved endurance, enabling it to perform reliably for substantial data write requirements.
General Information
CategoryHard drives
DescriptionLenovo ThinkSystem 7500 PRO - SSD - Read Intensive - encrypted - 15.36 TB - hot-swap - 2.5" - U.3 PCIe 4.0 x4 (NVMe) - 3072-bit RSA - TCG Opal Encryption 2.01, Self-Encrypting Drive (SED) - CRU
ManufacturerLenovo
MSRP$38,199.00
UNSPSC43201803
Main Specifications
Dimensions & Weight / Depth100 mm
Dimensions & Weight / Height15 mm
Dimensions & Weight / Weight200 g
Dimensions & Weight / Width70 mm
Hard Drive / Capacity15.36 TB
Hard Drive / Form Factor2.5"
Hard Drive / Hard Drive TypeHot-swap hard drive
Hard Drive / InterfaceU.3 PCIe 4.0 x4 (NVMe)
Hard Drive / InterfaceU.3 PCIe 4.0 x4 (NVMe)
Header / BrandMicron
Packaged Quantity1
Service & Support / Type1-year warranty
Storage / TypeSolid state drive
Environmental Parameters
Humidity Range Operating5 - 95% (non-condensing)
Max Operating Temperature70 °C
Max Storage Temperature85 °C
Min Operating Temperature0 °C
Min Storage Temperature-40 °C
Shock Tolerance (non-operating)1500 g @ 0.5 ms
Vibration Tolerance (non-operating)9.1 gRMS @ 5-800 Hz
Expansion & Connectivity
Compatible Bay2.5"
Interfaces1 x U.3 PCIe 4.0 x4 (NVMe)
General
Capacity15.36 TB
Depth100 mm
Device TypeSolid state drive - hot-swap
Encryption Algorithm3072-bit RSA
Features232-layer TLC NAND technology, Advanced ECC Engine, End-to-end data protection, advanced power loss protection architecture, Adaptive thermal monitoring, Secure Execution Environment, Asymmetric Roots of Trust, Strong Asymmetric Key Support, RSA Delegation Key Support, Secure Boot, Key-Based Firmware Update, Key-Based Privileged Access, S.M.A.R.T.
Form Factor2.5"
Hardware EncryptionYes
Height15 mm
InterfaceU.3 PCIe 4.0 x4 (NVMe)
NAND Flash Memory Type3D triple-level cell (TLC)
Weight200 g
Width70 mm
Manufacturer Warranty
Service & SupportLimited warranty - replacement - 1 year
Miscellaneous
Compliant StandardsEN55024 Class B, EN55032 Class B, RoHS, FCC, 47 CFR Part 15 Class B, UL, EN 60950-1 Second Edition, IEC 60950-1:2005 Second Edition, EN 60950-1:2006+A1:2010+A11:2009 + A12:2011 + A2:2013, BSMI CNS 13438 Class B, BSMI CNS 15663, RCM, AS/NZS CISPR 32 Class B, KC, RRL, KCC KN32 Class B, KCC KN35 Class B, WEEE 2012/19/EC, TUV, IEC60950/EN60950, VCCI, VCCI 2015.04 Class B, IC, ICES-003 Class B, Morocco, UkrSEPRO, UKCA, SI 2016/1091 Class B, SI 2012/3032 RoHS
Included AccessoriesHot-plug tray
Pricing TypeCustomer-replaceable Unit (CRU)
Performance
4KB Random Read1100000 IOPS
4KB Random Write250000 IOPS
Average Latency15 µs
Drive ClassRead Intensive
Drive Writes Per Day (DWPD)1
Internal Data Rate7000 MBps (read) / 5900 MBps (write)
SSD Endurance28032 TB
Power
Power Consumption
  • 15.5 watt (read)
  • 18.3 watt (write)
Reliability
MTBF2,000,000 hours
Non-Recoverable Errors1 per 10^17
