Lenovo - SFP+ transceiver module

Be the first to review this product

Availability: Out of stock

SKU

4XC1S00744

Compare with Similar items

Request a Quote

Questions before you move forward?

Chat with a JTF expert in Springfield, VA.

Click and connect instantly.

secure transaction

Details

The ThinkStation 10GbE Multimode SFP+ Transceiver is designed for use in 10-Gigabit Ethernet links over multimode fiber. Digital diagnostics functions are available via a 2-wire serial interface. Besides, it provides an enhanced digital diagnostic monitoring interface, which allows real-time access to device operating parameters such as transceiver temperature, laser bias current, transmitted optical power, received optical power and transceiver supply voltage.

Specifications

General Information
Category	Transceivers
Description	Lenovo - SFP+ transceiver module - 10GbE - 10GBase-SR, 10GBase-SW - up to 400 m
Manufacturer	Lenovo
MSRP	$64.99
UNSPSC	43201553
Main Specifications
Dimensions & Weight / Depth	0.85 cm
Dimensions & Weight / Height	1.37 cm
Dimensions & Weight / Weight	66 g
Dimensions & Weight / Width	5.66 cm
Header / Brand	Lenovo
Networking / Connectivity Technology	Wired
Networking / Data Link Protocol	10 Gigabit Ethernet
Networking / Data Transfer Rate	10.5 Gbps
Networking / Form Factor	Plug-in module
Networking / Type	SFP+ transceiver module
Packaged Quantity	1
Service & Support / Type	1-year warranty
Dimensions & Weight
Depth	0.85 cm
Height	1.37 cm
Weight	66 g
Width	5.66 cm
Dimensions & Weight (JTFpping)
JTFpping Depth	13.5 cm
JTFpping Height	3.5 cm
JTFpping Weight	185 g
JTFpping Width	13.5 cm
Environmental Parameters
Humidity Range Operating	5 - 95% RH
Max Operating Temperature	70 °C
Min Operating Temperature	0 °C
Expansion / Connectivity
Interfaces	1 x 10Gb Ethernet - SFP+
General
Device Type	SFP+ transceiver module
Form Factor	Plug-in module
Manufacturer Warranty
Service & Support	Limited warranty - 1 year
Miscellaneous
Compliant Standards	BSMI, EMC, FCC, sDoC, OM4, RoHS
Networking
Cabling Type	10GBase-SR, 10GBase-SW
Connectivity Technology	Wired
Data Link Protocol	10GbE
Data Transfer Rate	10.5 Gbps
Max Transfer Distance	400 m
Software / System Requirements
OS Required	Windows 11
