IP REMOTE CONTROL UNIT

Be the first to review this product

Availability: In stock

SKU

RMIP10

UPC Code

027242278820

Compare with Similar items

Request a Quote

Questions before you move forward?

Chat with a JTF expert in Springfield, VA.

Click and connect instantly.

secure transaction

Details

With the RM-IP10 IP controller, the BRC-H900, BRC-Z700, BRC-Z330, SRG-300SE, SRG-300H, SRG-120DH and SRG-10DU can be controlled though an IP network. Depending on the BRC camera model, the use of the proper IP Control Interface Board, either the BRBK-IP10 or BRBK-IP7Z is also required for compatibility. This functionality allows for flexible configurations, and enables the installation of up to 112 units of BRC cameras and up to five units of RM-IP10 controller depending on customer requirements.

Control of up to 112 BRC cameras via IP: The RM-IP10 remote control panel gives you control of up to 112 BRC cameras over an IP network.
Additional ability to use VISCA control: The RM-IP10 can also control up to 7 BRC cameras over a traditional VISCA (Video System Control Architecture) network.
Compatible with Sony's BRC-H900, BRC-H800, BRC-X1000, SRG-300SE, SRG300H, SRG-120DU, SRG-120DH and SRG120DS cameras: The RM-IP10 is compatible with Sony's BRC-H900, BRC-H800, BRC-X1000, SRG-300SE, SRG300H, SRG-120DU, SRG-120DH and SRG120DS cameras when they are fitted with the BRBK-IP10 option board, and the BRC-Z700 camera when it is fitted with the BRBK-IP7Z option board.
Simple RJ-45 (10Base-T/100Base-TX) connection for easy connection: The RM-IP10 links to an IP network with via a RJ-45 connector providing very easy, low cost and speedy installation.
Up to 5 controllers can operate on a single network: Up to 5 RM-IP10 control panels can be used on a single network allowing shared control and simultaneous multi-operator control of large camera systems.
PC configuration software supplied: The RM-IP10 provides for convenient configuration of system IPs and BRCs numbers, with location free configuration of anetwork.
Simultaneous Preset recall to all cameras under control: Instantaneous set-up of multiple cameras provides a big time saving for camera adjustments.

Specifications

General Information
Category	Remote control
Description	IP REMOTE CONTROL UNIT
Manufacturer	Sony
MSRP	$2,060.00
UNSPSC	52161525
Main Specifications
Dimensions & Weight / Weight	5.5
Height	9.37
Lead Time	20
Lead Time Effective Date	12/05/22
Length	19.133
List Price	1585.66
Quantity Measurement	EA
Unit of Measure	IN
UPC	027242860308
Width	10.314
Connections
Connector Type	1 x LAN (RJ-45) 1 x serial output (8 pin mini-DIN) 2 x serial 1 x DC power input
General
Connectivity Technology	Cable
Depth	14.59 cm
Device Type	Camera remote control
Features	Joystick, joystick lock button
Height	16.5 cm
Supported Devices	Camera
Weight	1 kg
Width	39.12 cm
Network
Network Protocols Supported	IP
