Intel X550-T2 - Network adapter
Get affordable, full line-rate performance with CAT 6a cabling or better at distances up to 100 meters and support for business and virtualization features with the Intel X550 10GBASE-T Dual Port NIC.
- Dual-port 10 Gigabit Ethernet throughput: Improve response times and alleviate bottlenecks that impact the performance of next-generation data centers with 20 Gbps full-duplex Ethernet transfer rate per port.
- 5X the size of a standard 1500-byte Ethernet frame: Achieve high-throughput performance and improve CPU utilization for database transfer and tape backup operations with support for jumbo frames and up to a 9.5K byte (KB) transmission unit (MTU) when running Ethernet I/O traffic.
- TCP/IP Stateless offloading: Optimize host efficiency and leave the CPU available for other duties with support for TCP/IP stateless offloading.
- Virtual local area network (VLAN) protocol support: Separate each physical port into multiple virtual NICs to isolate traffic between users for added network segmentation and enhanced security and performance.
| General Information | |
|---|---|
| Category | Network interface cards |
| Description | Intel X550-T2 - Network adapter - PCIe 3.0 x4 - 10Gb Ethernet x 2 - for Workstation Z2 G4, Z2 G5, Z4 G4, Z6 G4, Z8 G4; ZCentral 4R |
| Manufacturer | HP, Inc. |
| UNSPSC | 43201404 |
| Main Specifications | |
| Dimensions & Weight / Depth | 13.2 cm |
| Dimensions & Weight / Height | 6.9 cm |
| Header / Brand | Intel |
| Networking / Connectivity Technology | Wired |
| Networking / Data Link Protocol | 10 Gigabit Ethernet |
| Networking / Data Transfer Rate | 10 Gbps |
| Networking / Type | Network adapter |
| Packaged Quantity | 1 |
| Compatibility Information | |
| Designed For |
|
| Dimensions & Weight | |
| Depth | 13.2 cm |
| Height | 6.9 cm |
| Environmental Parameters | |
| Max Operating Temperature | 55 °C |
| Min Operating Temperature | 0 °C |
| Expansion / Connectivity | |
| Interfaces | 2 x 10Gb Ethernet - RJ-45 |
| General | |
| Device Type | Network adapter |
| Form Factor | Plug-in card |
| Interface (Bus) Type | PCI Express 3.0 x4 |
| Miscellaneous | |
| Compliant Standards | FCC Class B certified, UL, VCCI, BSMI, C-Tick, KCC, ICES-003 |
| Included Accessories | Low-profile bracket |
| Networking | |
| Connectivity Technology | Wired |
| Data Link Protocol | 10 Gigabit Ethernet |
| Data Transfer Rate | 10 Gbps |
| Ports | 10Gb Ethernet x 2 |
| Status Indicators | Link/activity, port transmission speed |
| Power | |
| Power Consumption Operational | 11.2 Watt |
