HPE Networking Instant On Switch Series 1960 48-Port Gb Smart-Managed Layer 2+ Ethernet Switch with PoE | 48x 1G | 2X 10GBase-T
From the brand Security. Easy set up. Performance. Check, check, check.
Explore simpler, smarter Wi-Fi from HPE Networking Instant On to accelerate your small business. Access Points
Visit the Store Switches
Visit the Store Bundles
Visit the Store Accessories
Visit the Store Product description 1960 12-Port 4 SFP+ Switch (JL805A) 1960 24-Port 2SFP+ Switch (JL806A) 1960 24-Port 2SFP+ PoE Switch (JL807A) 1960 48-Port 2SFP+ Switch (JL808A) 1960 48-Port 2SFP+ PoE Switch (JL809A) 1960 Multi-Gig Access PoE Switch (S0F35A) Add to Cart Add to Cart Add to Cart Add to Cart Add to Cart Add to Cart Customer Reviews 3.5 out of 5 stars
4 5.0 out of 5 stars
1 5.0 out of 5 stars
2 4.7 out of 5 stars
3 4.2 out of 5 stars
7 5.0 out of 5 stars
2 Price $1,444.99$1,444.99
$679.99$679.99
$1,049.99$1,049.99
$955.90$955.90
$1,799.99$1,799.99
$1,062.99$1,062.99 Gigabit and Uplink Ports 12 100/1000/10GBASE-T ports 4 SFP+ 10 GbE ports
24 10/100/1000 ports | 2 SFP+ 10GbE ports | 2 10GBASE-T ports
24 10/100/1000 PoE Ports | 2 SFP+ 10 GbE ports |
2 10GBASE-T ports
48 10/100/1000 Ports | 2 SFP+ 10 GbE ports |
2 10GBASE-T ports
48 10/100/1000 Ports | 2 SFP+ 10 GbE ports |
2 10GBASE-T PoE ports
8 10/100/1000GBase-T ports 4 1/2.5GbE Base-T ports Dimensions 350.5(D) x 442.5(W) x 43.95(H) mm
350.5(D) x 442.5(W) x 43.95(H) mm
350.5(D) x 442.5(W) x 43.95(H) mm
350.5(D) x 442.5(W) x 43.95(H) mm
350.5(D) x 442.5(W) x 43.95(H) mm
350(D) x 443(W) x 43.9(H) mm Weight 9.6 lb (4.3kg)
8.7 lb (3.9kg)
10.4 lb (4.7kg)
9.8 lb (4.4kg)
10.8 lb (4.9kg)
1.55 lb (5.24 kg) Throughput Capacity (Mpps) 238 Mpps
95 Mpps
95 Mpps
131 Mpps
131 Mpps
172 Mpps Switching Capacity 320 GB
128 GB
128 GB
176 GB
176 GB
116 GB Reliability MTBF (years) 88.8
123
65.3
109.4
68
40.8 PoE Power no data no data Total 370 W PoE Power (Up to 240W of Class 6 or 370 W
of Class 4 PoE)
no data Total 600 W PoE Power (Up to 480 W
of Class 6 or 600 W of Class 4 PoE)
Total 480 W PoE power (Up to 240 W of Class 6 or 240 W of Class 4 PoEThe Instant On 1960 48G 2XGT 2SFP+ PoE switch is an advanced, smart-managed, stackable Layer 2+ gigabit Ethernet switch designed for growing businesses. Stack up to four 1960 switches and manage through one single IP address simplifying network operations and providing flexibility for future network expansion. Features 600W of Class4 PoE on 40 ports and Class 6 PoE on 8 ports to power access points, cameras, IP phones, and other IoT devices EASY SET UP AND MANAGEMENT: Set up, manage, and monitor your Instant On switches and access points from any device using the Instant On mobile app or web browser –no subscription required. Guided step-by-step instructions to install devices and get your network up and running quickly –no technical expertise required. Stack up to four 1960 switches with Local Stacking and Cloud-Managed Stacking (using the Instant On mobile app or cloud-based web portal) CONFIGURATION: Rack-width design with rack mounting ears for rack or wall or flat-surface mount. Ports and LEDs facing the front. LUGGAGE TAG: Each Instant On 1960 switch contains a pull-out tag (luggage tag) complete with a QR code with switch ID information—perfect for easy pairing with the Instant On mobile app HIGH-PERFORMANCE: Features 52 active ports | 48x gigabit 10/100/1000/1000 with 2x 10GBase-T and 2x 1G/10G SFP+ uplink ports | 10G capable copper RJ45 ports and fiber-capable SFP+ slots | Power over Ethernet: Class 4 PoE on 40 ports and Class 6 PoE on 8 ports | PoE power budget 600 Watts WARRANTY & SUPPORT: Manage your network with confidence thanks to an industry-leading limited lifetime warranty and support
Explore simpler, smarter Wi-Fi from HPE Networking Instant On to accelerate your small business. Access Points
Visit the Store Switches
Visit the Store Bundles
Visit the Store Accessories
Visit the Store Product description 1960 12-Port 4 SFP+ Switch (JL805A) 1960 24-Port 2SFP+ Switch (JL806A) 1960 24-Port 2SFP+ PoE Switch (JL807A) 1960 48-Port 2SFP+ Switch (JL808A) 1960 48-Port 2SFP+ PoE Switch (JL809A) 1960 Multi-Gig Access PoE Switch (S0F35A) Add to Cart Add to Cart Add to Cart Add to Cart Add to Cart Add to Cart Customer Reviews 3.5 out of 5 stars
4 5.0 out of 5 stars
1 5.0 out of 5 stars
2 4.7 out of 5 stars
3 4.2 out of 5 stars
7 5.0 out of 5 stars
2 Price $1,444.99$1,444.99
$679.99$679.99
$1,049.99$1,049.99
$955.90$955.90
$1,799.99$1,799.99
$1,062.99$1,062.99 Gigabit and Uplink Ports 12 100/1000/10GBASE-T ports 4 SFP+ 10 GbE ports
24 10/100/1000 ports | 2 SFP+ 10GbE ports | 2 10GBASE-T ports
24 10/100/1000 PoE Ports | 2 SFP+ 10 GbE ports |
2 10GBASE-T ports
48 10/100/1000 Ports | 2 SFP+ 10 GbE ports |
2 10GBASE-T ports
48 10/100/1000 Ports | 2 SFP+ 10 GbE ports |
2 10GBASE-T PoE ports
8 10/100/1000GBase-T ports 4 1/2.5GbE Base-T ports Dimensions 350.5(D) x 442.5(W) x 43.95(H) mm
350.5(D) x 442.5(W) x 43.95(H) mm
350.5(D) x 442.5(W) x 43.95(H) mm
350.5(D) x 442.5(W) x 43.95(H) mm
350.5(D) x 442.5(W) x 43.95(H) mm
350(D) x 443(W) x 43.9(H) mm Weight 9.6 lb (4.3kg)
8.7 lb (3.9kg)
10.4 lb (4.7kg)
9.8 lb (4.4kg)
10.8 lb (4.9kg)
1.55 lb (5.24 kg) Throughput Capacity (Mpps) 238 Mpps
95 Mpps
95 Mpps
131 Mpps
131 Mpps
172 Mpps Switching Capacity 320 GB
128 GB
128 GB
176 GB
176 GB
116 GB Reliability MTBF (years) 88.8
123
65.3
109.4
68
40.8 PoE Power no data no data Total 370 W PoE Power (Up to 240W of Class 6 or 370 W
of Class 4 PoE)
no data Total 600 W PoE Power (Up to 480 W
of Class 6 or 600 W of Class 4 PoE)
Total 480 W PoE power (Up to 240 W of Class 6 or 240 W of Class 4 PoEThe Instant On 1960 48G 2XGT 2SFP+ PoE switch is an advanced, smart-managed, stackable Layer 2+ gigabit Ethernet switch designed for growing businesses. Stack up to four 1960 switches and manage through one single IP address simplifying network operations and providing flexibility for future network expansion. Features 600W of Class4 PoE on 40 ports and Class 6 PoE on 8 ports to power access points, cameras, IP phones, and other IoT devices EASY SET UP AND MANAGEMENT: Set up, manage, and monitor your Instant On switches and access points from any device using the Instant On mobile app or web browser –no subscription required. Guided step-by-step instructions to install devices and get your network up and running quickly –no technical expertise required. Stack up to four 1960 switches with Local Stacking and Cloud-Managed Stacking (using the Instant On mobile app or cloud-based web portal) CONFIGURATION: Rack-width design with rack mounting ears for rack or wall or flat-surface mount. Ports and LEDs facing the front. LUGGAGE TAG: Each Instant On 1960 switch contains a pull-out tag (luggage tag) complete with a QR code with switch ID information—perfect for easy pairing with the Instant On mobile app HIGH-PERFORMANCE: Features 52 active ports | 48x gigabit 10/100/1000/1000 with 2x 10GBase-T and 2x 1G/10G SFP+ uplink ports | 10G capable copper RJ45 ports and fiber-capable SFP+ slots | Power over Ethernet: Class 4 PoE on 40 ports and Class 6 PoE on 8 ports | PoE power budget 600 Watts WARRANTY & SUPPORT: Manage your network with confidence thanks to an industry-leading limited lifetime warranty and support
| General Information | |
|---|---|
| Category | Network switches |
| Description | HPE Networking Instant On 1960 48G 40p Class4 8p Class6 PoE 2XGT 2SFP+ 600W Switch - Switch - managed - 48 x 10/100/1000 + 2 x 10 Gigabit SFP+ + 2 x 100/1000/10GBase-T - rack-mountable - PoE (600 W) |
| Manufacturer | Hewlett Packard Enterprise |
| MSRP | $2,605.00 |
| UNSPSC | 43222612 |
| Main Specifications | |
| Dimensions & Weight / Depth | 40.275 cm |
| Dimensions & Weight / Height | 4.395 cm |
| Dimensions & Weight / Weight | 4.9 kg |
| Dimensions & Weight / Width | 44.25 cm |
| Header / Brand | HPE |
| Miscellaneous / Product Color | White |
| Networking / Form Factor | Rack-mountable |
| Networking / Ports Qty | 48 |
| Networking / Type | Switch |
| Packaged Quantity | 1 |
| Dimensions & Weight | |
| Depth | 40.275 cm |
| Height | 4.395 cm |
| Weight | 4.9 kg |
| Width | 44.25 cm |
| Environmental Parameters | |
| Humidity Range Operating | 15 - 95% (40 °C) |
| Max Operating Temperature | 40 °C |
| Max Storage Temperature | 70 °C |
| Min Operating Temperature | 0 °C |
| Min Storage Temperature | -40 °C |
| Expansion / Connectivity | |
| Interfaces |
|
| General | |
| Authentication Method | RADIUS |
| Capacity |
|
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.1ab (LLDP), IEEE 802.1D, IEEE 802.1s, IEEE 802.1Q, IEEE 802.1p |
| Device Type | Switch - 48 ports - managed |
| Enclosure Type | Rack-mountable 1U |
| Features | EEE, ARP support, auto-uplink (auto MDI/MDI-X), DHCP support, TPM, VLAN support, auto voice VLAN, LLDP-MED, LACP, STP support, BPDU Filter, flow control, IPv6 support, auto-negotiation, ACL support, CoS, port mirroring, full duplex mode, half duplex mode |
| Jumbo Frame Support | 9216 bytes |
| MAC Address Table Size | 16000 entries |
| Performance |
|
| PoE Budget | 600 W |
| Ports | 48 x 10/100/1000 + 2 x 10 Gigabit SFP+ + 2 x 100/1000/10GBase-T |
| Power Over Ethernet (PoE) | PoE |
| Processor | 1 x ARM: 800 MHz |
| Remote Management Protocol | RADIUS, SNMP 1, SNMP 2c, SNMP 3, HTTP, HTTPS |
| Routing Protocol | Static IP routing |
| Status Indicators | Port status, power |
| Subtype | Gigabit Ethernet |
| Miscellaneous | |
| Compliant Standards | IEC/EN60950-1:2006 +A11:2009 +A1:2010 +A12:2011 +A2:2013, IEC/EN 62368-1, UL 62368-1, UL 62368-1 Second Edition, UL 62368-1 Third Edition, CAN/CSA C22.2 No. 62368-1 Third Edition, CAN/CSA C22.2 No. 62368-1 Second Edition, IEC/EN 60825-1:2014 Class 2, EN 55032:2015 Class A, CISPR 32:2015 Class A, FCC CFR47 Part 15 B Class A 2018, ICES-003 Class A, VCCI Class A, CNS 13438 Class A, KN32 Class A, AS/NZS CISPR 32 Class A, EN 55035, CISPR 35, KN35, IEC/EN 61000-4-2, IEC/EN 61000-4-3, IEC/EN 61000-4-4, IEC/EN 61000-4-5, IEC/EN 61000-4-6, IEC/EN 61000-4-8, IEC/EN 61000-4-11, EN 61000-3-2, IEC 61000-3-2, IEC 61000-3-3, EN 61000-3-3 |
| MTBF | 68 years |
| Power | |
| Power Device | Internal power supply |
| Voltage Required | AC 100-240 V (50/60 Hz) |
Write Your Own Review
Quick Shipping
Usually ships in 1 business day
Product Overview
The Instant On 1960 48G 2XGT 2SFP+ PoE switch is an advanced, smart-managed, stackable Layer 2+ gigabit Ethernet switch designed for growing businesses. Stack up to four 1960 switches and manage through one single IP address simplifying network operations and providing flexibility for future network expansion. Features 600W of Class4 PoE on 40 ports and Class 6 PoE on 8 ports to power access points, cameras, IP phones, and other IoT devices
EASY SET UP AND MANAGEMENT: Set up, manage, and monitor your Instant On switches and access points from any device using the Instant On mobile app or web browser –no subscription required. Guided step-by-step instructions to install devices and get your network up and running quickly –no technical expertise required. Stack up to four 1960 switches with Local Stacking and Cloud-Managed Stacking (using the Instant On mobile app or cloud-based web portal)
CONFIGURATION: Rack-width design with rack mounting ears for rack or wall or flat-surface mount. Ports and LEDs facing the front. LUGGAGE TAG: Each Instant On 1960 switch contains a pull-out tag (luggage tag) complete with a QR code with switch ID information—perfect for easy pairing with the Instant On mobile app
HIGH-PERFORMANCE: Features 52 active ports | 48x gigabit 10/100/1000/1000 with 2x 10GBase-T and 2x 1G/10G SFP+ uplink ports | 10G capable copper RJ45 ports and fiber-capable SFP+ slots | Power over Ethernet: Class 4 PoE on 40 ports and Class 6 PoE on 8 ports | PoE power budget 600 Watts
WARRANTY & SUPPORT: Manage your network with confidence thanks to an industry-leading limited lifetime warranty and support
