HP Mini IP Conference PC
- Simple setup: Setting up your conferencing space is fast and easy with an Intel ® processor 4 driven PC that has Microsoft Teams Rooms 1 preinstalled and compatibility with Microsoft Teams Rooms certified audio, video, and the Poly TC10 touch controller. 5
- A fast and robust connection keeps you on track: Count on the Poly TC10 touch controller 5 to manage your Microsoft Teams meeting from anywhere in the room. Simply connect it to the HP Mini Conferencing PC using a flexible Ethernet cable, and HP software 6 help ensure it can stay up and running all day.
- Strong security and manageability: Get a highly secure and manageable PC that has the self-healing protection of HP Sure Start Gen7 7 and easy device management through Microsoft Endpoint Manager with HP Manageability Integration Kit.
- Help protect our shared future: At least 50 percent of all plastic used in this PC is post-consumer recycled plastic. 8 The outer box packaging is 100 percent sustainably sourced.
- Conference room ready: Get powerful performance from Windows IoT 9 and an Intel ® processor.
- Expand your solution: Easily connect your certified audio, video, and Poly TC10 controller to the HP Mini IP Conferencing PC with Microsoft Teams Rooms for a great conference room experience.
- Automatic recovery from firmware attacks: Firmware attacks can completely devastate your PC. Stay protected with HP’s self-healing BIOS—HP Sure Start Gen7 automatically recovers the BIOS from malware, rootkits, or corruption.
- Easy management with Poly Lens: Easily manage the system and connected Poly peripherals remotely using Poly Lens 10 , providing IT professionals with efficient control and maintenance capabilities.
- Get PC images right the first time: Rest easy with a PC that goes the distance and is designed to pass 120,000 hours of HP Total Test Process 11 and undergoes MIL-STD 810 testing 12 . Help protect your PC from dust ingress with an optional removable dust filter. 13
- Built-in durability: Rest easy with a PC that goes the distance and is designed to pass 120,000 hours of HP Total Test Process 11 and undergoes MIL-STD 810 testing 12 . Help protect your PC from dust ingress with an optional removable dust filter. 13
- What's in the box: HP Mini IP Conference PC with Microsoft Team Rooms Ethernet LAN POE cable (10 m) DisplayPort to HDMI Video Adapter 150W External Power Adapter External Power Adapter AC Power cable (1.8 m regional) Desktop Mini Port Cover Dual VESA Sleeve V3 Power Supply Holder V4
| General Information | |
|---|---|
| Category | Desktop computers |
| Description | HP Mini IP Conference PC - Mini desktop Core i7 13700T / up to 4.9 GHz - vPro - RAM 16 GB - SSD 256 GB - NVMe - UHD Graphics 770 - Gigabit Ethernet, 2.5 Gigabit Ethernet, IEEE 802.11ax (Wi-Fi 6E), Bluetooth 5.3 - Win 11 IoT Enterprise - monitor: none - with Microsoft Team Rooms |
| Manufacturer | HP, Inc. |
| UNSPSC | 43211507 |
| Main Specifications | |
| Chassis / Form Factor | Ultra small form factor |
| Dimensions & Weight / Depth | 17.5 cm |
| Dimensions & Weight / Height | 3.4 cm |
| Dimensions & Weight / Weight | 1.42 kg |
| Dimensions & Weight / Width | 17.7 cm |
| Display / Type | None. |
| Hard Drive / Capacity | 256 GB |
| Header / Brand | HP |
| Header / Country Kits | United States |
| Header / Localization | English |
| Mainboard / Chipset Type | Intel Q670 |
| Miscellaneous / Product Color | Black |
| Networking / Data Link Protocol |
|
| Networking / Wireless LAN Supported | Yes |
| Networking / Wireless Protocol |
|
| Optical Storage / Drive Type | No optical drive |
| Optical Storage / Type | None |
| OS Provided / Type | Windows 11 IoT Enterprise |
| Packaged Quantity | 1 |
| Processor / Clock Speed | 1.4 GHz |
| Processor / Generation | 13 |
| Processor / Manufacturer | Intel |
| Processor / Number of Cores | 16-core |
| Processor / Processor Number | I7-13700T |
| Processor / Type | Core i7 |
| RAM / Form Factor | SO-DIMM 262-pin |
| RAM / Memory Speed | 2400 MHz |
| RAM / Technology | DDR5 SDRAM |
| System / Hard Drive Capacity | 256 GB |
| System / Platform Technology | Intel vPro Platform |
| System / Type | Personal computer |
| Video Output / Graphics Processor | Intel UHD Graphics 770 |
| Video Output / HDCP compatible | Yes |
| Audio Output | |
| Compliant Standards | High Definition Audio |
| Max Sampling Rate | 192 kHz |
| Sound Output Mode | Stereo |
| Cache Memory | |
| Cache Per Processor | 30 MB |
| Installed Size | L3 cache - 30 MB |
| Dimensions & Weight | |
| Depth | 17.5 cm |
| Height | 3.4 cm |
| Weight | 1.42 kg |
| Width | 17.7 cm |
| Dimensions & Weight (JTFpping) | |
| JTFpping Depth | 11.4 cm |
| JTFpping Height | 25.1 cm |
| JTFpping Weight | 2.95 kg |
| JTFpping Width | 49.2 cm |
| Environmental Parameters | |
| Humidity Range Operating | 10 - 90% RH (non-condensing) |
| Max Operating Temperature | 35 °C |
| Min Operating Temperature | 10 °C |
| Expansion / Connectivity | |
| Bays | 1 (total) / 1 (free) x internal 2.5" |
| Interfaces |
|
| Slots |
|
| General | |
| Bundled with | Microsoft Team Rooms |
| Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
| Localization | Language: English / region: United States |
| Platform Technology | Intel vPro Platform |
| Product Form Factor | Mini desktop |
| Type | Personal computer |
| Graphics Controller | |
| Graphics Processor | Intel UHD Graphics 770 Dynamic Video Memory Technology |
| HDCP Compatible | Yes |
| Video Interfaces | HDMI, DisplayPort |
| Hard Drive | |
| Capacity | 1 x 256 GB |
| Features | NVM Express (NVMe) |
| Interface Type | PCI Express |
| Type | SSD - M.2 2280 |
| Miscellaneous | |
| Security Slot Type | Kensington security slot |
| Theft/Intrusion Protection | Security lock slot (cable lock sold separately), retractable padlock loop |
| Monitor | |
| Monitor Type | None. |
| Networking | |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.11d, IEEE 802.1x, IEEE 802.11i, Wi-Fi CERTIFIED, IEEE 802.11h, IEEE 802.11e, IEEE 802.11k, IEEE 802.3az, IEEE 802.11r, IEEE 802.11v |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 2.5 Gigabit Ethernet, IEEE 802.11ax (Wi-Fi 6E), Bluetooth 5.3 |
| Ethernet Controller | Intel I219-LM |
| Features | Wake on LAN (WoL), ACPI support, auto-uplink (auto MDI/MDI-X), MU-MIMO Support, PXE 2.1 support, dual stream (2x2) |
| Interface (Bus) Type | PCI Express Mini Card (M.2) |
| Remote Management Protocol | SNMP 2 |
| Wireless LAN Supported | Yes |
| Wireless NIC | Intel Wi-Fi 6E AX 211 |
| Operating System / Software | |
| OS Provided | Windows 11 IoT Enterprise English |
| Software | HP Image Assistant (free download), HP Sure Sense, Microsoft Teams Rooms, Poly Lens management software, HP Manageability Integration Kit (free download), HP Sure Start Gen7, HP Console Control, HP Sure Start |
| Optical Storage | |
| Type | No optical drive |
| Power | |
| Device Type | Power adapter |
| Efficiency | 89% (230VAC), 88% (115VAC) |
| Power Factor Correction | Yes (active) |
| Power Provided | 150 watt |
| Voltage Required | AC 90-264 V (50/60 Hz) |
| Processor / Chipset | |
| Chipset Type | Intel Q670 |
| Clock Speed | 1.4 GHz (P-core) / 1 GHz (E-core) |
| CPU | Intel Core i7 (13th Gen) 13700T |
| CPU Qty | 1 |
| CPU Upgradability | Upgradable |
| L2 cache | 24 MB |
| Max CPU Qty | 1 |
| Max Turbo Speed | 4.9 GHz (P-core) / 3.6 GHz (E-core) |
| Number of Cores | 16-core |
| Processor Main Features | Intel Turbo Boost Technology |
| RAM | |
| Configuration Features | 2 x 8 GB |
| Effective Memory Speed | 2400 MHz |
| Form Factor | SO-DIMM 262-pin |
| Installed Size | 16 GB (installed) / 64 GB (max) |
| Rated Memory Speed | 2400 MHz |
| Slots | 2 (total) / 0 (empty) |
| Technology | DDR5 SDRAM |
| Storage Controller | |
| Controller Interface Type | SATA-600 / NVMe |
| Type | 1 x SATA/NVMe |
| Sustainability Information | |
| TCO Certified | TCO Certified Desktops 9 |
Onsite Service
Following your purchase, JTF will assign an authorized service partner in your area to your account. Your service calls are processed and dispatched in just minutes after they are received, thus minimizing your downtimes. All service partners are authorized, factory trained and 100% endorsed by JTF Network Partners, with over 600 service dealers nationwide*
Same Day Onsite Service:
Same Day Service is provided at your business or home during the contracted Maintenance period.
Exceptions:
1) Your offices are 40 miles away from the closest service providers.
2) Service in HI, AK & PR.
Convenient Assistance:
Having device issues?
Experts are here 8am -6pm weekly to help solve your technical problems.
Fast, free replacements:
If we can’t fix your printer, we’ll try to replace it by the next business day.
No hidden fees:
Parts and labor, replacements, even return shipping — it’s all covered by your JTF Warranty.
Optional extra coverage:
Additional coverage to include supplies are available for purchase.
No Expert Install
$249.00 Expert Install
Installation Service for equipment includes the following:
JTF will schedule an appointment with one person per site. Unless otherwise requested and/or scheduled, the standard practice is to start all installation services within one week the delivery of the hardware to the customer’s location.
Unpacking: JTF will inventory the shipment against the packing list, unpack and install all delivered products.
Setup/Installation: JTF will physically assemble, connect peripherals, network cables, and power cords that were purchased from JTF.
a. This service provides installation of drivers on a single PC workstation (not server), network setup, including the programming of the IP address and network settings and verification of the network functionality, wireless connection setup and verification of the functionality over the Internet.
b. For configuration networking, the Customer can choose between automatic configuration using BOOTCP or Dynamic Host Configuration Protocol (DHCP), or manual configuration with IP address, default gateway, and subnet mask.
c. For multifunction products, the service provides setup of the ‘send to email configuration’ and configuration of the SMTP or LDAP.
d. This service provides the Customer-identified key operator with a basic overview on how to install consumables, plus explanations of basic features and functionality such as drivers, control panel features, embedded Web server, and alerts.
secure transaction
Quick Details
- Mini desktop Core i7 13700T / up to 4.9 GHz
- vPro
- RAM 16 GB
- SSD 256 GB
- NVMe
