HP Mini Conference G9
- Ready to run right out of the box: Setting up your conferencing space is fast and easy with an Intel ® processor 4 driven PC that has Zoom Rooms 1 preinstalled and broad compatibility with your choice of audio, video, and touch controls. 5
- Customize your setup: Seamlessly deploy this PC into your existing Zoom Rooms 1 environment, where it can drive up to three displays. 2 Get more room to work by taking the PC entirely off the conference room table and mounting 3 on a wall or under a table with the integrated VESA plate.
- Strong security and manageability: Get a highly secure and manageable PC that has the self-healing protection of HP Sure Start Gen7 6 and easy device management through Microsoft Endpoint Manager with HP Manageability Integration Kit. 7
- Conference room ready: Get powerful performance from Windows IoT 8 and an Intel ® processor.
- Expand your solution: Easily connect your certified audio, video, and Poly TC10 controller to the HP Mini Conferencing PC with Zoom Rooms for a great conference room experience.
- Automatic recovery from firmware attacks: Firmware attacks can completely devastate your PC. Stay protected with HP’s self-healing BIOS—HP Sure Start Gen7 automatically recovers the BIOS from malware, rootkits, or corruption.
- Easy management with Poly Lens: Easily manage the system and connected Poly peripherals remotely using Poly Lens 9 , providing IT professionals with efficient control and maintenance capabilities.
- Get PC images right the first time: Improve the quality and security of custom Windows images with HP Image Assistant which assists ITDMs with image creation, identifies problems, and provides recommendations and remediation.
- Built-in durability: Rest easy with a PC that goes the distance and is designed to pass 120,000 hours of HP Total Test Process 10 and undergoes MIL-STD 810 testing. 11 Help protect your PC from dust ingress with an optional removable dust filter. 12
- What's in the box: HP Mini Conference G9 PC with Zoom Rooms DisplayPort to HDMI Video Adapter 90W External Power Adapter External Power Adapter AC Power cable(1.8 m regional) Dual VESA Sleeve V3 Power Supply Holder V4
| General Information | |
|---|---|
| Category | Desktop computers |
| Description | HP Mini Conference G9 - With Zoom Rooms - mini desktop Core i7 12700T / up to 4.7 GHz - vPro - RAM 16 GB - SSD 256 GB - NVMe, TLC - UHD Graphics 770 - Gigabit Ethernet, IEEE 802.11ax (Wi-Fi 6E), Bluetooth 5.3 - Win 10 IoT Enterprise - monitor: none |
| Manufacturer | HP, Inc. |
| UNSPSC | 43211507 |
| Main Specifications | |
| Chassis / Form Factor | Ultra small form factor |
| Dimensions & Weight / Depth | 17.5 cm |
| Dimensions & Weight / Height | 3.4 cm |
| Dimensions & Weight / Weight | 1.42 kg |
| Dimensions & Weight / Width | 17.7 cm |
| Display / Type | None. |
| Hard Drive / Capacity | 256 GB |
| Hard Drive / Interface | PCI Express 4.0 x4 |
| Hard Drive / Interface Type | PCI Express 4.0 x4 |
| Header / Brand | HP |
| Header / Country Kits | United States |
| Header / Localization | English |
| Mainboard / Chipset Type | Intel Q670 |
| Miscellaneous / Product Color | Black |
| Networking / Data Link Protocol |
|
| Networking / Wireless LAN Supported | Yes |
| Networking / Wireless Protocol |
|
| Optical Storage / Drive Type | No optical drive |
| Optical Storage / Type | None |
| OS Provided / Type | Windows 10 IoT Enterprise |
| Packaged Quantity | 1 |
| Processor / Clock Speed | 1.4 GHz |
| Processor / Generation | 12 |
| Processor / Manufacturer | Intel |
| Processor / Number of Cores | 12-core |
| Processor / Processor Number | I7-12700T |
| Processor / Type | Core i7 |
| RAM / Form Factor | DIMM 288-pin |
| RAM / Memory Speed | 4800 MHz |
| RAM / Technology | DDR5 SDRAM |
| System / Hard Drive Capacity | 256 GB |
| System / Platform Technology | Intel vPro Platform |
| System / Type | Personal computer |
| Video Output / Graphics Processor | Intel UHD Graphics 770 |
| Video Output / HDCP compatible | Yes |
| Audio Output | |
| Compliant Standards | High Definition Audio |
| Max Sampling Rate | 192 kHz |
| Sound Output Mode | Stereo |
| Cache Memory | |
| Cache Per Processor | 25 MB |
| Installed Size | L3 cache - 25 MB |
| Dimensions & Weight | |
| Depth | 17.5 cm |
| Height | 3.4 cm |
| Weight | 1.42 kg |
| Width | 17.7 cm |
| Dimensions & Weight (JTFpping) | |
| JTFpping Depth | 13.2 cm |
| JTFpping Height | 23.5 cm |
| JTFpping Weight | 2.95 kg |
| JTFpping Width | 49.8 cm |
| Environmental Parameters | |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Max Operating Temperature | 35 °C |
| Min Operating Temperature | 10 °C |
| Expansion / Connectivity | |
| Bays | 1 (total) / 1 (free) x internal 2.5" |
| Interfaces |
|
| Slots |
|
| General | |
| Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
| Localization | Language: English / region: United States |
| Platform Technology | Intel vPro Platform |
| Product Form Factor | Mini desktop |
| Type | Personal computer |
| Graphics Controller | |
| Graphics Processor | Intel UHD Graphics 770 |
| HDCP Compatible | Yes |
| Video Interfaces | HDMI, DisplayPort |
| Hard Drive | |
| Capacity | 1 x 256 GB |
| Features | NVM Express (NVMe), triple-level cell (TLC) |
| Interface Type | PCI Express 4.0 x4 |
| Type | SSD - M.2 2280 |
| Miscellaneous | |
| Compliant Standards | FCC Class B certified, ICES-003, CCC, FIPS 140-2 Level 2, RoHS, UL 60950-1, CSA C22.2 No. 60950-1-07, WEEE, KCC Class B, Common Criteria EAL4+, CECP, VCCI Class B, SEPA, low halogen, UL 62368-1, CAN/CSA-C22.2 No. 62368-1-14, IEEE 1680.1 |
| Security Slot Type | Kensington security slot |
| Theft/Intrusion Protection | Security lock slot (cable lock sold separately), padlock loop |
| Monitor | |
| Monitor Type | None. |
| Networking | |
| Compliant Standards | IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.1x, IEEE 802.11i, Wi-Fi CERTIFIED, IEEE 802.3az |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6E), Bluetooth 5.3 |
| Ethernet Controller | Intel I219-LM |
| Features | Wake on LAN (WoL), auto-uplink (auto MDI/MDI-X), MU-MIMO Support, PXE 2.1 support, dual stream (2x2) |
| Interface (Bus) Type | PCI Express Mini Card (M.2) |
| Remote Management Protocol | SNMP 2 |
| Wireless LAN Supported | Yes |
| Wireless NIC | Intel Wi-Fi 6E AX 211 |
| Operating System / Software | |
| OS Provided | Windows 10 IoT Enterprise English |
| Software | HP Support Assistant, HP PC Hardware Diagnostics UEFI, Microsoft 365 (Trial), HP Secure Erase, HP Setup Integrated OOBE, HP Notifications, HP Connection Optimizer, HP Sure Click, HP Privacy Settings, HP Cloud Recovery, HP Sure Sense, HP Sure Admin, HP QuickDrop, HP BIOSphere Gen6, HP DriveLock, myHP, HP Desktop Support Utilities, HP Client Security Manager Gen7, HP Touchpoint Customizer, HP Easy Clean, HP Smart Support, HP Connect for Microsoft Endpoint Manager, HP SureRun Gen5, HP Sure Recover Gen5, HP Wolf Security for Business, HP Sure Start Gen7 |
| Optical Storage | |
| Type | No optical drive |
| Power | |
| Device Type | Power adapter |
| Efficiency | 89% (230VAC), 88% (115VAC) |
| Power Factor Correction | Yes (active) |
| Power Provided | 90 watt |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Processor / Chipset | |
| Chipset Type | Intel Q670 |
| Clock Speed | 1.4 GHz (P-core) / 1 GHz (E-core) |
| CPU | Intel Core i7 (12th Gen) 12700T |
| CPU Qty | 1 |
| L2 cache | 12 MB |
| Max CPU Qty | 1 |
| Max Turbo Speed | 4.7 GHz (P-core) / 3.4 GHz (E-core) |
| Number of Cores | 12-core |
| Processor Main Features | Hyper-Threading Technology, Intel Turbo Boost Technology 2, Intel Smart Cache, Intel Turbo Boost Max 3.0 |
| RAM | |
| Configuration Features | 2 x 8 GB |
| Effective Memory Speed | 4800 MHz |
| Form Factor | DIMM 288-pin |
| Installed Size | 16 GB (installed) / 64 GB (max) |
| Rated Memory Speed | 4800 MHz |
| Slots | 2 (total) / 0 (empty) |
| Technology | DDR5 SDRAM |
| Storage Controller | |
| Controller Interface Type | SATA-600 / NVMe |
| Type | 1 x SATA/NVMe |
| Sustainability Information | |
| ENERGY STAR Certified | Yes |
Onsite Service
Following your purchase, JTF will assign an authorized service partner in your area to your account. Your service calls are processed and dispatched in just minutes after they are received, thus minimizing your downtimes. All service partners are authorized, factory trained and 100% endorsed by JTF Network Partners, with over 600 service dealers nationwide*
Same Day Onsite Service:
Same Day Service is provided at your business or home during the contracted Maintenance period.
Exceptions:
1) Your offices are 40 miles away from the closest service providers.
2) Service in HI, AK & PR.
Convenient Assistance:
Having device issues?
Experts are here 8am -6pm weekly to help solve your technical problems.
Fast, free replacements:
If we can’t fix your printer, we’ll try to replace it by the next business day.
No hidden fees:
Parts and labor, replacements, even return shipping — it’s all covered by your JTF Warranty.
Optional extra coverage:
Additional coverage to include supplies are available for purchase.
No Expert Install
$149.00 Expert Install
Installation Service for equipment includes the following:
JTF will schedule an appointment with one person per site. Unless otherwise requested and/or scheduled, the standard practice is to start all installation services within one week the delivery of the hardware to the customer’s location.
Unpacking: JTF will inventory the shipment against the packing list, unpack and install all delivered products.
Setup/Installation: JTF will physically assemble, connect peripherals, network cables, and power cords that were purchased from JTF.
a. This service provides installation of drivers on a single PC workstation (not server), network setup, including the programming of the IP address and network settings and verification of the network functionality, wireless connection setup and verification of the functionality over the Internet.
b. For configuration networking, the Customer can choose between automatic configuration using BOOTCP or Dynamic Host Configuration Protocol (DHCP), or manual configuration with IP address, default gateway, and subnet mask.
c. For multifunction products, the service provides setup of the ‘send to email configuration’ and configuration of the SMTP or LDAP.
d. This service provides the Customer-identified key operator with a basic overview on how to install consumables, plus explanations of basic features and functionality such as drivers, control panel features, embedded Web server, and alerts.
secure transaction
Quick Details
- With Zoom Rooms
- mini desktop Core i7 12700T / up to 4.7 GHz
- vPro
- RAM 16 GB
- SSD 256 GB
