HP Engage Flex Pro-C G2 Retail System

Be the first to review this product

Availability: Out of stock

SKU

8X098UA

Compare with Similar items

Request a Quote

Questions before you move forward?

Chat with a JTF expert in Springfield, VA.

Click and connect instantly.

secure transaction

Details

Drive business operations with a compact high-performance platform that also offers outstanding flexibility. Suitable for a wide range of deployments that span POS, digital signage, video surveillance, processing/controlling, OEM and more.

Operating System: FreeDOS
Memory (RAM): 16 GB DDR5-4800 MHz RAM (1 x 16 GB)GB
Processor: Intel ® Core ™ i5-13500E (up to 4.6 GHz Max Turbo frequency, 24 MB L3 cache, 14 cores, 20 threads)
Solid State Drive:
Maximize Flexibility. Minimize Space. (Flex Pro-C): With multiple connectivity, graphics, and networking options, plus the ability to accommodate a range of peripherals, this powerful platform can be configured for almost any environment and use case. You can also declutter & optimize tight spaces since this machine and a display can be powered with just one cord and power outlet.
Built to Perform. Designed to Last: Get high level, long-term performance from quality components like Intel ® 13th Generation processors 1 , up to 128GB DDR5 RAM, and multiple OS and port options. Plan ahead with a five-year lifecycle that lets you roll out on your schedule and extend protection with optional 5 years parts/service support. 2
Built-in Security and Manageability: Spend more time focusing on your business, not on technology. Enjoy automatic firmware intrusion detection and repair from day one with HP Sure Start Gen 7 3 and reduce the cost and complexity of managing your platform remotely with the HP Manageability Integration Kit. 4

Specifications

General Information
Category	Point of sale (POS) terminals
Description	HP Engage Flex Pro-C G2 Retail System - SFF 1 x Core i5 i5-13500E / up to 4.6 GHz - RAM 16 GB - SSD 256 GB - NVMe - UHD Graphics 770 - Gigabit Ethernet - FreeDOS - monitor: none
Manufacturer	HP, Inc.
UNSPSC	43211505
Main Specifications
Chassis / Form Factor	Small form factor
Dimensions & Weight / Depth	30.2 cm
Dimensions & Weight / Height	10 cm
Dimensions & Weight / Weight	3.9 kg
Dimensions & Weight / Width	30 cm
Display / Type	None.
Hard Drive / Capacity	256 GB
Header / Brand	HP
Mainboard / Chipset Type	Intel Q670
Miscellaneous / Product Color	Black
Networking / Data Link Protocol	Ethernet Fast Ethernet Gigabit Ethernet
Optical Storage / Drive Type	No optical drive
Optical Storage / Type	None
OS Provided / Type	FreeDOS
Packaged Quantity	1
Processor / Clock Speed	2.4 GHz
Processor / Generation	13
Processor / Manufacturer	Intel
Processor / Number of Cores	14-core
Processor / Processor Number	I5-13500E
Processor / Type	Core i5
RAM / Data Integrity Check	Non-ECC
RAM / Form Factor	DIMM 288-pin
RAM / Memory Speed	4800 MHz
RAM / Technology	DDR5 SDRAM
System / Hard Drive Capacity	256 GB
System / Type	Point of sale terminal
Video Output / Graphics Processor	Intel UHD Graphics 770
Video Output / HDCP compatible	Yes
Audio Output
Compliant Standards	High Definition Audio
Max Sampling Rate	192 kHz
Sound Output Mode	Stereo
Cache Memory
Cache Per Processor	24 MB
Installed Size	L3 cache - 24 MB
Dimensions & Weight
Depth	30.2 cm
Height	10 cm
Weight	3.9 kg
Width	30 cm
Dimensions & Weight (JTFpping)
JTFpping Depth	40 cm
JTFpping Height	49.9 cm
JTFpping Width	22.9 cm
Environmental Parameters
Humidity Range Operating	20 - 85% (non-condensing)
Max Operating Temperature	40 °C
Min Operating Temperature	10 °C
Expansion / Connectivity
Bays	2 internal 2.5"
Interfaces	3 x USB 3.2 Gen 1 (charging) 2 x USB 3.2 Gen 1 2 x USB 2.0 1 x DisplayPort 1.4 1 x LAN (Gigabit Ethernet) 1 x headphones/microphone
Slots	2 (total) / 2 (free) x PCIe - full-height (x1 mode) 1 (total) / 1 (free) x PCIe 4.0 x16 - half-height (x16 mode) 1 (total) / 1 (free) x PCIe 4.0 x16 - half-height (x4 mode) 2 (total) / 1 (free) x M.2 Card
General
Embedded Security	Trusted Platform Module (TPM 2.0) Security Chip
Product Form Factor	SFF
Sensors	HP Tamper Lock
Type	Point of sale terminal
Graphics Controller
Graphics Processor	Intel UHD Graphics 770 Dynamic Video Memory Technology
HDCP Compatible	Yes
Video Interfaces	DisplayPort
Hard Drive
Capacity	1 x 256 GB
Features	NVM Express (NVMe)
Interface Type	PCI Express
Type	SSD - M.2
Input Device
Type	Keyboard, no mouse
Keyboard
Interface	USB
Keyboard Name	HP 320K
Miscellaneous
Compliant Standards	VCCI, BSMI, GS, FCC, RoHS, KCC, WEEE, ICES, cULus, Common Criteria EAL4+, EAC, RCM, BIS, low halogen, IEC 950, Ukraine
Security Slot Type	Kensington security slot
Theft/Intrusion Protection	Security lock slot (cable lock sold separately), chassis intrusion sensor
Monitor
Monitor Type	None.
Networking
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet
Ethernet Controller	Intel I219-LM
Features	Wake on LAN (WoL), ACPI support, auto-uplink (auto MDI/MDI-X), PXE 2.1 support
Remote Management Protocol	SNMP 2
Operating System / Software
OS Provided	FreeDOS
Optical Storage
Type	No optical drive
Power
Device Type	Power supply
Efficiency	90%
Power Factor Correction	Yes (active)
Power Provided	250 watt
Voltage Required	AC 90-264 V (50/60 Hz)
Processor / Chipset
Chipset Type	Intel Q670
Clock Speed	2.4 GHz (P-core) / 1.5 GHz (E-core)
CPU	Intel Core i5 (13th Gen) i5-13500E
CPU Qty	1
CPU Upgradability	Upgradable
L2 cache	11.5 MB
Max CPU Qty	1
Max Turbo Speed	4.6 GHz (P-core) / 3.3 GHz (E-core)
Number of Cores	14-core
Processor Main Features	Intel Turbo Boost Technology
RAM
Configuration Features	1 x 16 GB
Effective Memory Speed	4800 MHz
Form Factor	DIMM 288-pin
Installed Size	16 GB (installed) / 64 GB (max)
Rated Memory Speed	4800 MHz
Slots	4 (total) / 3 (empty)
Technology	DDR5 SDRAM - non-ECC
Storage Controller
Controller Interface Type	SATA 6Gb/s
Type	1 x SATA
