Formax FD 442 SmartFold Hybrid Folder
Formax FD 442 SmartFold Hybrid Folder
The FD 442 is a fast, fully automatic paper folder with hybrid feed options that handle a range of media—from delicate digital prints to heavy coated sheets. It boasts intuitive touchscreen controls, automatic fold setup, and high-output performance—perfect for busy print environments.
Formax FD 442 SmartFold Hybrid Folder
| Model | FD 442 |
| Feeding Method | Hybrid: Air-Suction + Friction Feed |
| Control Panel | 7" Full-Color Touchscreen with Job Memory |
| Max Folding Speed | Up to 20,000 sheets per hour |
| Paper Size – Min | 3.5″ W × 5″ L (89 × 127 mm) |
| Paper Size – Max | 13″ W × 20″ L (330 × 508 mm) |
| Paper Weight Range | 16 – 150 lb bond (60 – 250 gsm) |
| Feed Tray Capacity | Up to 800 sheets (20 lb bond / 75 gsm) |
| Standard Fold Types | Letter, Half, Z-Fold, Double Parallel, Gate, Fold-Out |
| Custom Fold Jobs | 50 programmable memory settings |
| Fold Adjustment | Automatic fold-plate + paper-length detection |
| Counters | Resettable batch & total counters |
| Output System | Long conveyor stacker with adjustable side guides |
| Noise Level | Quiet, office-suitable operation |
| Safety Features | Safety-door sensors, jam detection, automatic stop |
| Construction | Heavy-duty steel frame with adjustable leveling feet |
| Power Supply | 120V AC, 60 Hz |
| Dimensions (L × W × H) | 65″ × 24″ × 28″ (1,650 × 610 × 710 mm) |
| Net Weight | Approx. 140 lbs (64 kg) |
| Ideal For | High-volume print shops, digital finishers, in-plant operations |
Popup Text
No Expert Install
$149.00 Expert Install
Installation Service for equipment includes the following:
JTF will schedule an appointment with one person per site. Unless otherwise requested and/or scheduled, the standard practice is to start all installation services within one week the delivery of the hardware to the customer’s location.
Unpacking: JTF will inventory the shipment against the packing list, unpack and install all delivered products.
Setup/Installation: JTF will physically assemble, connect peripherals, network cables, and power cords that were purchased from JTF.
a. This service provides installation of drivers on a single PC workstation (not server), network setup, including the programming of the IP address and network settings and verification of the network functionality, wireless connection setup and verification of the functionality over the Internet.
b. For configuration networking, the Customer can choose between automatic configuration using BOOTCP or Dynamic Host Configuration Protocol (DHCP), or manual configuration with IP address, default gateway, and subnet mask.
c. For multifunction products, the service provides setup of the ‘send to email configuration’ and configuration of the SMTP or LDAP.
d. This service provides the Customer-identified key operator with a basic overview on how to install consumables, plus explanations of basic features and functionality such as drivers, control panel features, embedded Web server, and alerts.
