Cisco Catalyst 3560X-48P-L

Be the first to review this product

Availability: Out of stock

SKU

WS-C3560X-48P-L-RF

Compare with Similar items

Request a Quote

Questions before you move forward?

Chat with a JTF expert in Springfield, VA.

Click and connect instantly.

secure transaction

Details

The Cisco Catalyst 3560-X switch is an enterprise-class standalone switch. This switch provides security, energy efficiency, and ease of operation with innovative features. The Cisco Catalyst 3560-X enhances productivity by enabling applications such as IP telephony, wireless, and video for borderless network experience.

Specifications

General Information
Category	Network switches
Description	Cisco Catalyst 3560X-48P-L - Switch - managed - 48 x 10/100/1000 (PoE) - rack-mountable - PoE - remanufactured
Manufacturer	Cisco Systems
UNSPSC	43222612
Main Specifications
Dimensions & Weight / Depth	46 cm
Dimensions & Weight / Height	4.5 cm
Dimensions & Weight / Weight	7.4 kg
Dimensions & Weight / Width	44.5 cm
Header / Brand	Cisco
Networking / Form Factor	Rack-mountable
Networking / Ports Qty	48
Networking / Type	Switch
Packaged Quantity	1
Dimensions & Weight
Depth	46 cm
Height	4.5 cm
Weight	7.4 kg
Width	44.5 cm
Environmental Parameters
Humidity Range Operating	5 - 95% (non-condensing)
Max Storage Temperature	70 °C
Min Operating Temperature	-5 °C
Min Storage Temperature	-40 °C
Expansion / Connectivity
Expansion Slots	1 (total) / 1 (free) x expansion slot
Interfaces	48 x 10Base-T/100Base-TX/1000Base-T - RJ-45 PoE 1 x USB Type A 1 x console - mini-USB Type B management 1 x RS-232 - RJ-45 management 1 x 10Base-T/100Base-TX - RJ-45 management
General
Authentication Method	Kerberos, Secure Shell (SSH), RADIUS, TACACS+
Capacity	Virtual interfaces (VLANs): 255
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ae, IEEE 802.3at
Device Type	Switch - 48 ports - managed
Enclosure Type	Rack-mountable 1U
Features	Hot swap module replacement, layer 2 switching, dynamic IP address assignment, DHCP support, PoE, auto-negotiation, ARP support, trunking, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, Syslog support, traffic shaping, Broadcast Storm Control, High Availability, Multicast Storm Control, Unicast Storm Control, RSTP support, DHCP snooping, DTP support, PAgP support, TFTP support, ACL support, QoS, Jumbo Frames support, MLD snooping, DAI, PoE+, PVST+, UDLD, SRR, LACP, RSPAN
Flash Memory	128 MB
Jumbo Frame Support	9216 bytes
Performance	Switching fabric bandwidth: 160 Gbps
Ports	48 x 10/100/1000 (PoE)
Power Over Ethernet (PoE)	PoE
RAM	256 MB
Remote Management Protocol	SNMP 1, SNMP 2, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, TFTP, SSH, CLI
Status Indicators	Port status, port transmission speed, port duplex mode, power, system, link/activity
Subtype	Gigabit Ethernet
Miscellaneous
Compliant Standards	TUV GS, CISPR 22 Class A, GOST, cUL, NOM, VCCI Class A ITE, EN55022 Class A, CB, AS/NZS 60950-1, AS/NZ 3548 Class A, CCC, RoHS, UL 60950-1, IEC 60950-1, EN 60950-1, KCC, FCC Part 15 A, CSA C22.2 No. 60950-1
Pricing Type	Remanufactured
Rack Mounting Kit	Included
Power
Features	Redundant Power System (RPS) connector
Installed Qty	1
Max Supported Qty	2
Power Device	Internal power supply
Power Redundancy	Optional
Power Redundancy Scheme	1+1 (with optional power supply)
Voltage Required	AC 120/230 V (50/60 Hz)
Software / System Requirements
Software Included	Cisco IOS LAN Base
