APC Smart-UPS X SMX2000RMLV2U

Availability: In stock
SKU
SMX2000RMLV2U-US
Request a Quote
Questions before you move forward?

Chat with a JTF expert in Springfield, VA.

Click and connect instantly.

secure transactionsecure transaction
This APC Smart-UPS is designed for IT managers or network administrators to maintain business uptime, data transfer and continuity during prolonged power outages. The 1920VA line interactive 2U rack/tower UPS provides pure sine wave power to support critical electronics during power disruptions. The SMX comes with NEMA 5-20P input, 3x NEMA 5-15R, 3x NEMA 5-20R and 1x NEMA L5-20R outlets. The UPS has a SmartSlot for optional Network Management Card that enables graceful shutdown of physical servers, virtual machines & HCI Clusters via PowerChute Network Shutdown. This uninterrupted power supply can connect to EcoStruxure IT or third-party centralized management platforms. The SMX UPS has a 3-year warranty, and the built-in lead-acid battery has a 2-year warranty. This is compatible with dedicated user-replaceable battery, and the APC replacement battery cartridge helps restore UPS performance to the original specifications. The Smart-UPS comes with a pair of tower-mounting stabilizing feet and rack-mounting brackets. The Smart-UPS is compliant with the Trade Agreements Act (TAA) requirements. The Emergency Power Off feature enables the UPS to remotely shutdown during emergencies.
Product image SMX2000RMLV2U-US
Product image SMX2000RMLV2U-US
  • Yes, Smart-UPS SMX2000RMLV2U-US supports up to 10 APC external battery pack SMX120RMBP2U.:
  • Select models with an "NC" suffix come with the network management card preinstalled.:
  • APC’s patented ‘green’ mode bypass components that perform AVR when not needed. This results in higher efficiencies across a wide range of load conditions.:
  • Switched outlet groups provide greater control, allowing you to reboot hung devices, program sequenced on-and-off and non-critical load shedding of equipment.:
  • PowerChute Serial Shutdown is available for download from the apc.com. It is a UPS management software enabling graceful system shutdown in the event of an extended power outage and provides energy management capabilities for desktops, servers, and workstations.:
General Information
CategoryRechargeable batteries
DescriptionAPC Smart-UPS X SMX2000RMLV2U - UPS (rack-mountable / external) - line interactive, 3x 5-15R, 3x 5-20R, 1x L5-20NR SmartSlot, extended runtime - AC 120 V - 1800 Watt - 2000 VA - 1-phase - RS-232, USB - output connectors: 7 - 2U - 2.4 m cord - United States - black - APC Take-Back - TAA Compliant
ManufacturerAPC by Schneider Electric
MSRP$3,515.00
UNSPSC26111701
Main Specifications
Dimensions & Weight / Depth66.7 cm
Dimensions & Weight / Height8.5 cm
Dimensions & Weight / Weight38.45 kg
Dimensions & Weight / Width43.2 cm
Header / BrandAPC
Header / Country KitsUnited States
Miscellaneous / Product ColorBlack
Networking / Remote Management Interface
  • RS-232
  • USB
Packaged Quantity1
Power Device / Form FactorRack-mountable / external
Power Device / Output Connector Qty7
Power Device / Power Capacity (VA)2000 VA
Power Device / UPS TechnologyLine interactive
Power Device / Voltage Required
  • AC 100-127 V
  • AC 120 V
Product TypeUPS
Service & Support / Type3-year warranty
Battery
Recharge Time3 hours
Run Time (Up To)
  • 10.56 min at full load
  • 27.37 min at half load
TechnologyLead acid
Transfer Time4 ms
Dimensions & Weight
Depth66.7 cm
Height8.5 cm
Weight38.45 kg
Width43.2 cm
Dimensions & Weight (JTFpping)
JTFpping Depth86.9 cm
JTFpping Height24.3 cm
JTFpping Weight45.36 kg
JTFpping Width59.6 cm
Environmental Parameters
Humidity Range Operating0 - 95%
Max Operating Temperature40 °C
Min Operating Temperature0 °C
Sound Emission55 dBA
Expansion / Connectivity
Expansion Slots1 (total) / 1 (free) x SmartSlot
Interfaces
  • 1 x management (RS-232) - 9 pin D-Sub (DB-9)
  • 1 x management (USB) - 4 pin USB Type B
  • 1 x EPO (emergency power off)
General
ColorBlack
Cord Length2.4 m
Device TypeUPS - rack-mountable / external
Height (Rack Units)2U
LocalizationUnited States
Manufacturer Warranty
Service & Support
  • Limited warranty - 3 years
  • Limited warranty - battery - 2 years
Miscellaneous
Cables IncludedPower cable 2.4 m
Compliant StandardsBSMI, EU RoHS, REACH
FeaturesPCE package, audible alarm, LCD display, auto-sensing
Pricing TypeAPC Take-Back
Rack Mounting KitIncluded
TAA CompliantYes
Networking
Remote Management InterfaceRS-232, USB
Power Device
Efficiency97.7% at 100% Load, 96.2% at 25% Load, 97.5% at 50% Load, 97.8% at 75% Load
Frequency Provided50/60 Hz ± 3Hz
Frequency Required50/60 Hz
Input ConnectorsPower NEMA 5-20P
Input VoltageAC 120 V
Input Voltage RangeAC 100 - 120 V
Input Wiring1-phase
Output VoltageAC 120 V ± 5% - 50/60 Hz
Output WaveformSinewave
Power Capacity1800 Watt / 2000 VA
Power Output Connectors Details
  • 3 x power NEMA 5-15R
  • 3 x power NEMA 5-20R
  • 1 x power NEMA L5-20R
Surge Energy Rating540 Joules
Surge SuppressionYes
UPS TechnologyLine interactive
