APC Smart-UPS SMTL1500RM3UCNC
- The Lithium-Ion batteries used in Smart-UPS can last 8 to 10 years or 3000
charge/discharge cycles. Valve Regulated Lead
Acid (VRLA) batteries typically last 3 to 5 years or 200 discharge cycles.: - No. Smart-UPS with Lithium-ion batteries are up to 65% lighter than Lead Acid VRLA UPS.:
- No. Batteries for Smart-UPS with Lithium-ion are not compatible with Smart-UPS with VRLA batteries.:
- The Smart-UPS Lithium-ion have the AP9641 UPS network management card with environmental monitoring pre-installed.:
- There is a 5-year warranty for both the electronics and the internal batteries.:
- All new devices are on-boarded to the Standard plan with remote power monitoring, UPS and power events, automated distribution of firmware to UPSs with one-click remote installation and downloadable asset and renewal reports. Advanced Plan option provides UPS Outlet Group reboot for remote power cycling of connected IT equipment. Features vary with terms of use.:
| General Information | |
|---|---|
| Category | Rechargeable batteries |
| Description | APC Smart-UPS SMTL1500RM3UCNC - UPS (rack-mountable / external) - AC 120 V - 1350 Watt - 1500 VA - 1-phase - RS-232, USB, Ethernet 10/100/1000 - output connectors: 6 - 3U - black, silver - APC Take-Back - with APC Network Management Card 3 with Environmental Monitoring AP9641 |
| Manufacturer | APC by Schneider Electric |
| MSRP | $4,490.00 |
| UNSPSC | 26111701 |
| Main Specifications | |
| Dimensions & Weight / Depth | 30.2 cm |
| Dimensions & Weight / Height | 13.1 cm |
| Dimensions & Weight / Weight | 19.5 kg |
| Dimensions & Weight / Width | 43.8 cm |
| Header / Brand | APC |
| Miscellaneous / Product Color |
|
| Networking / Remote Management Interface |
|
| Packaged Quantity | 1 |
| Power Device / Form Factor | Rack-mountable / external |
| Power Device / Output Connector Qty | 6 |
| Power Device / Power Capacity (VA) | 1500 VA |
| Power Device / UPS Technology | Line interactive |
| Power Device / Voltage Required |
|
| Product Type | UPS |
| Service & Support / Type | 5-year warranty |
| Battery | |
| Recharge Time | 2 hours |
| Run Time (Up To) |
|
| Technology | Lithium ion |
| Dimensions & Weight | |
| Depth | 30.2 cm |
| Height | 13.1 cm |
| Weight | 19.5 kg |
| Width | 43.8 cm |
| Dimensions & Weight (Shipping) | |
| Shipping Depth | 44.8 cm |
| Shipping Height | 27.9 cm |
| Shipping Weight | 22.68 kg |
| Shipping Width | 58.4 cm |
| Environmental Parameters | |
| Humidity Range Operating | 0 - 95% (non-condensing) |
| Max Operating Temperature | 40 °C |
| Min Operating Temperature | 0 °C |
| Sound Emission | 45 dBA |
| Expansion / Connectivity | |
| Expansion Slots | 1 (total) / 0 (free) x SmartSlot |
| Interfaces |
|
| General | |
| Bundled with | APC Network Management Card 3 with Environmental Monitoring AP9641 |
| Color | Black, silver |
| Device Type | UPS - rack-mountable / external |
| Height (Rack Units) | 3U |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 5 years |
| Miscellaneous | |
| Cables Included |
|
| Compliant Standards | CSA, NOM, UL 1778, FCC Part 15 A, CSA C22.2 No. 107.3, UL 1973 |
| Equipment Protection Value | 150000 US Dollars |
| Features | User-replaceable removable battery, audible alarm, LCD display |
| Pricing Type | APC Take-Back |
| Networking | |
| Remote Management Interface | RS-232, USB, Ethernet 10/100/1000 |
| Power Device | |
| Frequency Provided | 50/60 Hz ± 3Hz |
| Frequency Required | 50/60 Hz ± 3Hz |
| Input Connectors | 1 x power NEMA 5-15P |
| Input Voltage | AC 120 V |
| Input Voltage Range | AC 82 - 144 V |
| Input Voltage Range (Adjustable) | AC 75 - 154 V |
| Input Wiring | 1-phase |
| Output Voltage | AC 120 V ± 5% - 50/60 Hz |
| Output Waveform | Sinewave |
| Power Capacity | 1350 watt / 1500 VA |
| Power Output Connectors Details | 6 x power NEMA 5-15R |
| Surge Energy Rating | 680 joules |
| Surge Suppression | Yes |
| UPS Technology | Line interactive |
| Sustainability Information | |
| Packaging Recycled Content | Made of recycled cardboard |
