APC Smart-UPS 750VA LCD
This APC Smart-UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. The 750VA line interactive tower UPS provides pure sine wave power to support critical electronics during power disruptions. It comes with NEMA 5-15P input and 6 NEMA 5-15R outlets. It offers cloud-based remote power monitoring, UPS firmware upgrades, remote diagnostics and proactive email notifications with recommended actions. It has a SmartSlot for optional Network Management Card that enables graceful shutdown of physical servers, virtual machines & HCI Clusters via PowerChute Network Shutdown. The UPS can connect to EcoStruxure IT or third-party centralized management platforms. It provides surge protection against lightning strikes, power sags, brownouts and surges. The SMT UPS has a 3-year warranty, and built-in lead-acid battery has a 2-year warranty. It is compatible with a dedicated user-replaceable battery, and the APC replacement battery cartridge helps restore UPS performance to the original specifications.



- Smart-UPS SMT range is for small to medium businesses who do not have the time or resources to monitor their UPS devices but understand the importance of doing so, or who have trusted a Partner with this task.:
- Our vendor-neutral data center infrastructure management software, EcoStruxure™ IT, provides flexible deployment options to monitor critical equipment and can deliver insights such as smart alarms directly to your smartphone, making it ideal for customers requiring visibility into UPS, cooling, power and more.:
- All new devices are on-boarded to the Standard plan with remote power monitoring, UPS and power events, automated distribution of firmware to UPSs with one-click remote installation and downloadable asset and renewal reports. Upgrade to Advanced plan any time, to be able to remotely reboot connected IT equipment from the Cloud. Advanced plan is compatible with all SmartConnect devices, and ideal for SMT and other Smart-UPS models with Controllable Outlet Groups. Use the outlet group naming feature to track how your essential and non-essential equipment is plugged in. Use SmartConnect Advanced plan to power-cycle the controllable Outlet group independently from the UPS Main Group, to reboot connected IT equipment without having to go on site.:
- PowerChute Serial Shutdown is available for download from the apc.com. It is a UPS management software enabling graceful system shutdown in the event of an extended power outage and provides energy management capabilities for desktops, servers, and workstations.:
| General Information | |
|---|---|
| Category | Power conditioning equipment |
| Description | APC Smart-UPS 750VA LCD - UPS - AC 120 V - 500 Watt - 750 VA - Ethernet, RS-232, USB - output connectors: 6 - black - with APC SmartConnect |
| Manufacturer | APC by Schneider Electric |
| MSRP | $743.00 |
| UNSPSC | 39121000 |
| Main Specifications | |
| Dimensions & Weight / Depth | 36.9 cm |
| Dimensions & Weight / Height | 16.1 cm |
| Dimensions & Weight / Weight | 12.5 kg |
| Dimensions & Weight / Width | 13.8 cm |
| Header / Brand | APC |
| Miscellaneous / Product Color | Black |
| Networking / Remote Management Interface |
|
| Packaged Quantity | 1 |
| Power Device / Form Factor | External |
| Power Device / Output Connector Qty | 6 |
| Power Device / Power Capacity (VA) | 750 VA |
| Power Device / UPS Technology | Line interactive |
| Power Device / Voltage Required | AC 120 V |
| Product Type | UPS |
| Service & Support / Type | 3-year warranty |
| Battery | |
| Quantity | 1 |
| Recharge Time | 3 hours |
| Run Time (Up To) |
|
| Technology | Lead acid |
| Dimensions & Weight | |
| Depth | 36.9 cm |
| Height | 16.1 cm |
| Weight | 12.5 kg |
| Width | 13.8 cm |
| Dimensions & Weight (JTFpping) | |
| JTFpping Depth | 49.9 cm |
| JTFpping Height | 30.1 cm |
| JTFpping Weight | 14.02 kg |
| JTFpping Width | 27.8 cm |
| Environmental Parameters | |
| Humidity Range Operating | 0 - 95% |
| Max Operating Temperature | 40 °C |
| Min Operating Temperature | 0 °C |
| Sound Emission | 41 dBA |
| Expansion / Connectivity | |
| Expansion Slots | 1 (total) / 0 (free) x SmartSlot |
| Interfaces |
|
| General | |
| Bundled with | APC SmartConnect |
| Color | Black |
| Device Type | UPS - external |
| Manufacturer Warranty | |
| Service & Support |
|
| Miscellaneous | |
| Cables Included | Power cable 1.83 m |
| Compliant Standards | UL 1449, UL 1778, RoHS Exemption 7b |
| Features | User-replaceable removable battery, audible alarm, LCD display |
| Pricing Type | APC Take-Back |
| Networking | |
| Remote Management Interface | Ethernet, RS-232, USB |
| Power Device | |
| Circuit Protection | Circuit breaker |
| Frequency Provided | 47 - 53 / 57 - 63 Hz |
| Frequency Required | 50/60 Hz |
| Input Connectors | 1 x power NEMA 5-15 |
| Input Voltage | AC 120 V |
| Input Voltage Range | AC 82 - 144 V |
| Input Voltage Range (Adjustable) | AC 75 - 154 V |
| Input Wiring | 1-phase |
| Output Voltage | AC 120 V ± 5% - 47 - 53 / 57 - 63 Hz |
| Output Waveform | Sinewave |
| Power Capacity | 500 watt / 750 VA |
| Power Output Connectors Details | 6 x power NEMA 5-15R |
| Surge Energy Rating | 540 joules |
| Surge Response Time | 0 ns |
| Surge Suppression | Yes |
| UPS Technology | Line interactive |
| Software / System Requirements | |
| Software Included | Drivers & Utilities |
| Sustainability Information | |
| Packaging Recycled Content | Made of recycled cardboard |
