APC Smart-UPS 750VA LCD

Availability: In stock
SKU
SMT750C
UPC Code
731304325451
Request a Quote
Questions before you move forward?

Chat with a JTF expert in Springfield, VA.

Click and connect instantly.

secure transactionsecure transaction
This APC Smart-UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. The 750VA line interactive tower UPS provides pure sine wave power to support critical electronics during power disruptions. It comes with NEMA 5-15P input and 6 NEMA 5-15R outlets. It offers cloud-based remote power monitoring, UPS firmware upgrades, remote diagnostics and proactive email notifications with recommended actions. It has a SmartSlot for optional Network Management Card that enables graceful shutdown of physical servers, virtual machines & HCI Clusters via PowerChute Network Shutdown. The UPS can connect to EcoStruxure IT or third-party centralized management platforms. It provides surge protection against lightning strikes, power sags, brownouts and surges. The SMT UPS has a 3-year warranty, and built-in lead-acid battery has a 2-year warranty. It is compatible with a dedicated user-replaceable battery, and the APC replacement battery cartridge helps restore UPS performance to the original specifications.
Product image SMT750C
Product image SMT750C
  • Smart-UPS SMT range is for small to medium businesses who do not have the time or resources to monitor their UPS devices but understand the importance of doing so, or who have trusted a Partner with this task.:
  • Our vendor-neutral data center infrastructure management software, EcoStruxure™ IT, provides flexible deployment options to monitor critical equipment and can deliver insights such as smart alarms directly to your smartphone, making it ideal for customers requiring visibility into UPS, cooling, power and more.:
  • All new devices are on-boarded to the Standard plan with remote power monitoring, UPS and power events, automated distribution of firmware to UPSs with one-click remote installation and downloadable asset and renewal reports. Upgrade to Advanced plan any time, to be able to remotely reboot connected IT equipment from the Cloud. Advanced plan is compatible with all SmartConnect devices, and ideal for SMT and other Smart-UPS models with Controllable Outlet Groups. Use the outlet group naming feature to track how your essential and non-essential equipment is plugged in. Use SmartConnect Advanced plan to power-cycle the controllable Outlet group independently from the UPS Main Group, to reboot connected IT equipment without having to go on site.:
  • PowerChute Serial Shutdown is available for download from the apc.com. It is a UPS management software enabling graceful system shutdown in the event of an extended power outage and provides energy management capabilities for desktops, servers, and workstations.:
General Information
CategoryPower conditioning equipment
DescriptionAPC Smart-UPS 750VA LCD - UPS - AC 120 V - 500 Watt - 750 VA - Ethernet, RS-232, USB - output connectors: 6 - black - with APC SmartConnect
ManufacturerAPC by Schneider Electric
MSRP$743.00
UNSPSC39121000
Main Specifications
Dimensions & Weight / Depth36.9 cm
Dimensions & Weight / Height16.1 cm
Dimensions & Weight / Weight12.5 kg
Dimensions & Weight / Width13.8 cm
Header / BrandAPC
Miscellaneous / Product ColorBlack
Networking / Remote Management Interface
  • Ethernet
  • RS-232
  • USB
Packaged Quantity1
Power Device / Form FactorExternal
Power Device / Output Connector Qty6
Power Device / Power Capacity (VA)750 VA
Power Device / UPS TechnologyLine interactive
Power Device / Voltage RequiredAC 120 V
Product TypeUPS
Service & Support / Type3-year warranty
Battery
Quantity1
Recharge Time3 hours
Run Time (Up To)
  • 5 min at full load
  • 16 min at half load
TechnologyLead acid
Dimensions & Weight
Depth36.9 cm
Height16.1 cm
Weight12.5 kg
Width13.8 cm
Dimensions & Weight (JTFpping)
JTFpping Depth49.9 cm
JTFpping Height30.1 cm
JTFpping Weight14.02 kg
JTFpping Width27.8 cm
Environmental Parameters
Humidity Range Operating0 - 95%
Max Operating Temperature40 °C
Min Operating Temperature0 °C
Sound Emission41 dBA
Expansion / Connectivity
Expansion Slots1 (total) / 0 (free) x SmartSlot
Interfaces
  • 1 x management (RS-232) - RJ-45
  • 1 x management (USB) - 4 pin USB Type A
  • Management (Ethernet) - RJ-45
  • SmartConnect
General
Bundled withAPC SmartConnect
ColorBlack
Device TypeUPS - external
Manufacturer Warranty
Service & Support
  • Limited warranty - 3 years
  • Limited warranty - battery - 2 years
Miscellaneous
Cables IncludedPower cable 1.83 m
Compliant StandardsUL 1449, UL 1778, RoHS Exemption 7b
FeaturesUser-replaceable removable battery, audible alarm, LCD display
Pricing TypeAPC Take-Back
Networking
Remote Management InterfaceEthernet, RS-232, USB
Power Device
Circuit ProtectionCircuit breaker
Frequency Provided47 - 53 / 57 - 63 Hz
Frequency Required50/60 Hz
Input Connectors1 x power NEMA 5-15
Input VoltageAC 120 V
Input Voltage RangeAC 82 - 144 V
Input Voltage Range (Adjustable)AC 75 - 154 V
Input Wiring1-phase
Output VoltageAC 120 V ± 5% - 47 - 53 / 57 - 63 Hz
Output WaveformSinewave
Power Capacity500 watt / 750 VA
Power Output Connectors Details6 x power NEMA 5-15R
Surge Energy Rating540 joules
Surge Response Time0 ns
Surge SuppressionYes
UPS TechnologyLine interactive
Software / System Requirements
Software IncludedDrivers & Utilities
Sustainability Information
Packaging Recycled ContentMade of recycled cardboard
