APC Rack PDU 9000 Switched APDU9941

The APC Switched Rack PDU distributes reliable power within a rack through a single input and multiple output receptacles The APDU9941 offers advanced load management combined with remote on/off switching control of individual outlets for power cycling, delayed power sequencing, and outlet use management The 0U PDU includes a NEMA L6-30P input plug with 3 05m (10 ft) cord, (21) IEC 60320 C13/C15 and (3) IEC 60320 C19/C21 hybrid outlet receptacles The hybrid outlets allow 60°C operating temperature at full load, are compatible with standard C14 and C20 power cords, and are future-proofed for new C16 and C21 power cords required for higher temperature rated devices The Network Management Card provides enhanced cybersecurity with secured interfaces and modified password policy The rack PDU integrates with EcoStruxure IT through Network Management Card and can be accessed, configured, and managed remotely via Web, SNMP and Command Line Interface Color user-interactive LCD interface details current, real power, voltage, and energy measurements for local user access The outlet level control allows power on/off functionality for power recycling/reboot of remote equipment and restricts unauthorized use of individual outlets The Switched Rack PDU includes a temperature/humidity sensor port, locking IEC outlets when used with locking power cords, low-profile circuit breakers and USB port for local Firmware updates The rack PDU supports daisy-chain of up to 32 PDUs on a single IP address, thereby reducing networking cost The rack PDU comes with a standard three-year warranty.

• From the world's most trusted brand in PDUs now comes greater control of your rack IT equipment from the cloud to the edge with APC NetShelter 9000 Series Next Generation Rack PDUs that offer a more reliable, intelligent, and faster to deploy PDU. With Industry leading reliability, manageability, and security, APC Switched Rack PDU's provide advanced load management plus on/off outlet level power cycling and sequencing control. Power metering provides real-time remote monitoring of connected loads with alarms to warn of potential overloads. Users can access, configure, and control Switched Rack PDUs through secure Web, SNMP, and Redfish and are fully compatible with EcoStruxure IT.:
• Gigabit Ethernet Connectivity: Provides Gigabit Ethernet to enhance and standardize network connectivity across all assets in the data center.
• 60°C Operating Temperature: Ability to operate in a maximum ambient air temperature of 60°C (140°F) at full load increasing reliability and availability even in today's high density deployments. Other models allow up to 45°C (113°F).
• Hybrid Outlets: Available on select models, Industry first hybrid outlets allow 60°C operating temperature at full load, are fully compatible with standard C14 and C20 power cords, and future-proofed for implementation of higher temperature rated devices requiring C16 and C21 power cords.
• High Retention Outlets: With no special power cords required, high retention outlets provide up to twice the holding force to reduce risk of accidental disconnect. Lock outlets in place with optional APC 8700 series locking power cords.
• 1% Metering Accuracy: Providing the same level of accuracy as a utility company meter by adhering to IEC 62053-21 class 1, 1% metering accuracy provides peace of mind to use these PDUs to bill based on power usage. In addition, the higher level of accuracy provides more precision for capacity planning and threshold alarm monitoring.
• Gigabit Ethernet Connectivity: Provides Gigabit Ethernet to enhance and standardize network connectivity across all assets in the data center.
• 60°C Operating Temperature: Ability to operate in a maximum ambient air temperature of 60°C (140°F) at full load increasing reliability and availability even in today's high density deployments. Other models allow up to 45°C (113°F).
• Hybrid Outlets: Available on select models, Industry first hybrid outlets allow 60°C operating temperature at full load, are fully compatible with standard C14 and C20 power cords, and future-proofed for implementation of higher temperature rated devices requiring C16 and C21 power cords.
• High Retention Outlets: With no special power cords required, high retention outlets provide up to twice the holding force to reduce risk of accidental disconnect. Lock outlets in place with optional APC 8700 series locking power cords.
• 1% Metering Accuracy: Providing the same level of accuracy as a utility company meter by adhering to IEC 62053-21 class 1, 1% metering accuracy provides peace of mind to use these PDUs to bill based on power usage. In addition, the higher level of accuracy provides more precision for capacity planning and threshold alarm monitoring.
• Gigabit Ethernet Connectivity: Provides Gigabit Ethernet to enhance and standardize network connectivity across all assets in the data center.
• APC Network Management Card 3: •Color LCD Display | •Display aggregate current draw per PDU and much more! | •Enhanced cybersecurity with secured interfaces and modified password policy. | •Full-featured network management interfaces that provide standards-based management via Web, SNMP, and Redfish. | •Allows users to access, configure, and manage rack PDUs from remote locations to save valuable time.
• Zero U Toolless installation: Vertical toolless-mount for fast installation. Puts power where it is needed most - in the racks near the equipment. Seamless with APC NetShelter and most 3rd party racks.
• 32 PDU Network Port Sharing: Connect and manage up to 32 PDUs from one IP address to simplify and speed deployment while saving the cost required in having a dedicated network connection for each PDU.
• Wireless Connectivity*: Compatible with the optional APC USB WiFi Device (AP9834) for cableless connectivity over WiFi that speeds deployment and simplifies moves, adds, and changes. | *APC USB WiFi device (SKU AP9834) sold separately
• Zero U Toolless installation: Vertical toolless-mount for fast installation. Puts power where it is needed most - in the racks near the equipment. Seamless with APC NetShelter and most 3rd party racks.
• 32 PDU Network Port Sharing: Connect and manage up to 32 PDUs from one IP address to simplify and speed deployment while saving the cost required in having a dedicated network connection for each PDU.
• Wireless Connectivity*: Compatible with the optional APC USB WiFi Device (AP9834) for cableless connectivity over WiFi that speeds deployment and simplifies moves, adds, and changes. | *APC USB WiFi device (SKU AP9834) sold separately
• Zero U Toolless installation: Vertical toolless-mount for fast installation. Puts power where it is needed most - in the racks near the equipment. Seamless with APC NetShelter and most 3rd party racks.
