APC NetShelter 9000 Series Switched Rack PDU

The APC Switched Rack PDU distributes reliable power within a rack through a single input and multiple output receptacles. The APDU9965US offers advanced load management combined with remote on/off switching control of individual outlets for power cycling, delayed power sequencing, and outlet use management. The 0U PDU includes a NEMA L21-30P input plug with 1.83m (6ft) cord, (21) IEC 60320 C13/C15 and (3) IEC 60320 C19/C21 hybrid outlet receptacles. The hybrid outlets allow 60°C operating temperature at full load, are compatible with standard C14 and C20 power cords and are future-proofed for new C16 and C21 power cords required for higher temperature rated devices. The Network Management Card provides enhanced cybersecurity with secured interfaces and modified password policy. The rack PDU integrates with EcoStruxure IT through Network Management Card and can be accessed, configured, and managed remotely via Web, SNMP and Command Line Interface. Color user-interactive LCD interface details current, real power, voltage, and energy measurements for local user access. The outlet level control allows power on/off functionality for power recycling/reboot of remote equipment and restricts unauthorized use of individual outlets. The Switched Rack PDU includes a temperature/humidity sensor port, locking IEC outlets when used with locking power cords, low-profile circuit breakers and USB port for local Firmware updates The rack PDU supports daisy-chain of up to 32 PDUs on a single IP address, thereby reducing networking cost. The rack PDU comes with a standard three-year warranty. The switched PDU is compliant with the Trade Agreements Act (TAA) requirements.

• Yes, APC intelligent rack PDU supports remote monitoring using software such as Schneider Electric's EcoStruxure: TM | IT.
• Is this PDU UL certified?Yes, APC rack PDUs are UL certified.:
• The sales professional can assist you in designing a complete IT physical infrastructure solution that includes hardware, software and services. Begin with NetShelter: TM | racks integrated with NetShelter | TM | rack PDUs, Smart-UPS | TM | for backup power, NetBotz | TM | components for security and environmental monitoring, Aisle Containment, Cooling solutions and EcoStruxure | TM | IT for remote monitoring and administration.
• No, it does not affect the electrical output of the Rack PDU. It simply reboots the embedded Network Management Card, which will render the network port inaccessible for a short period while it reboots.:
• A firmware upgrade of the management interface will not power on/off any attached loads. The network management card will reboot during the process but will not affect the attached load.:
