APC InfraStruXure Central Enterprise

Be the first to review this product

Availability: Out of stock

SKU

AP9475

UPC Code

731304246039

Compare with Similar items

Request a Quote

Questions before you move forward?

Chat with a JTF expert in Springfield, VA.

Click and connect instantly.

secure transaction

Details

EcoStruxure IT Data Center Expert ('DCE') Enterprise Appliance provides remote monitoring and management capabilities for your Data Center. It supports up to 4025 devices and 250 surveillance cameras. It is part of the EcoStruxure IT DCIM suite of applications, which enables your business to manage their data centers across multiple domains. The DCE software collects, organizes, and distributes critical alerts, surveillance video, and key information, providing a unified view of complex physical infrastructure environments from anywhere on the network.

Specifications

General Information
Category	Control unit
Description	APC InfraStruXure Central Enterprise - Network management device - 100Mb LAN - rack-mountable - for P/N: AR3103SP, AR3106SP, SCL400RMJ1U, SCL500RMI1UNC, SMX2KR2UX145, SMX3KR2UNCX145
Manufacturer	APC by Schneider Electric
MSRP	$55,380.00
UNSPSC	43201542
Main Specifications
Dimensions & Weight / Depth	48.3 cm
Dimensions & Weight / Height	8.9 cm
Dimensions & Weight / Weight	25 kg
Dimensions & Weight / Width	71.1 cm
Header / Brand	APC
Networking / Data Link Protocol	Ethernet Fast Ethernet
Networking / Form Factor	Rack-mountable
Networking / Type	Network management device
Packaged Quantity	1
Service & Support / Type	2-year warranty
Compatibility Information
Designed For	P/N: ACDC2513, AP7950B, AR2200, AR2280, AR2400, AR2400FP1, AR2401, AR2407, AR2480, AR2487, AR2487G, AR2500, AR2507, AR2580, AR2587, AR3100G, AR3100TAA, AR3100W, AR3103SP, AR3105SP, AR3105W, AR3106SP, AR3107G, AR3107SP, AR3140G, AR3140W, AR3150SP, AR3150W, AR3155SP, AR3155W, AR3157SP, AR3300G, AR3300SP, AR3300W, AR3305SP, AR3305W, AR3307SP, AR3307W, AR3340G, AR3340W, AR3350SP, AR3350W, AR3355SP, AR3355W, AR3357SP, AR4000MVX429, AR4000MVX432, AR4018IX429, AR4018IX431, AR4018IX432, AR4018SP, AR4018SPX429, AR4018SPX431, AR4018SPX432, AR4018X429, AR4024IX429, AR4024IX431, AR4024IX432, AR4024SP, AR4024SPX429, AR4024SPX431, AR4024SPX432, AR4024X431, AR4038IX429, AR4038IX431, AR4038IX432, G35T15K3IS, G35T40K3IS, G3HT10K3IB1S, G3HT10KHLS, G3HT20K3IB1S, G3HT20K3IB2S, G3HT20K3ILS, G3HT20KHLS, G3HT30K3IB1S, G3HT30K3IB2S, G3HT30K3ILS, G3HT30KHLMS, G3HT30KHLS, G3HT40KHB1S, G3HT40KHL-INS, G3HTI40KHLS, G55TUPSM120HINS, G55TUPSM120HS, G55TUPSM20HB15S, G55TUPSM30HB15S, G55TUPSM30HS, G55TUPSM40HB15S, G55TUPSM40HS, G55TUPSM80HS, G55TUPSU20HS, G55TUPSU30HS, G55TUPSU40HB15S, G55TUPSU40HS, G55TUPSU60HB5S, GVMPB160KG65S, GVMPB160KGS, GVMPB160KHS, GVMPB180KG65S, GVMPB180KGS, GVMPB200KHS, GVMPB225KG65S, GVMPB225KGS, GVMRB160KG65S, GVMRB160KGS, GVMRB180KG65S, GVMRB180KGS, GVMRB225KG65S, GVMRB225KGS, GVMS160KGF65S, GVMS180KGF65S, GVMS225KGF65S, GVMSB160KG65S, GVMSB160KGS, GVMSB160KHS, GVMSB180KG65S, GVMSB180KGS, GVMSB200KHS, GVMSB225KG65S, GVMSB225KGS, NBPD0160A, NBWL0355A, NBWL0356A, SCL400RMJ1U, SCL500RMI1UNC, SMC1000-BR, SMC15002U-BR, SMC1500I-2U, SMC1500I2U-BR, SMC1500I-2UC, SMC1500I-BR, SMT3000I2U-BR, SMX2000LV, SMX2000LVNC, SMX2000LVNCUS, SMX2000LVUS, SMX2200R2HVNC, SMX2KR2UX145, SMX3000HV-BR, SMX3000HVT, SMX3000HVTUS, SMX3000LV, SMX3000LV2U-BR, SMX3000LVUS, SMX3KR2UNCX145, SRT1000RMXLA, SRT1000RMXLA-NC, SRT1000RMXLI, SRT1000RMXLI-NC, SRT1500RMXLA, SRT1500RMXLA-NC, SURT3000XLI-ET, SURT5000XLIX438, SUVTJP20KF2B4S, SY30K40E, SYAF8KRMTX424
Environmental Parameters
Humidity Range Operating	5 - 90%
Max Operating Temperature	35 °C
Min Operating Temperature	10 °C
Expansion / Connectivity
Interfaces	2 x 100Base-TX - RJ-45 1 x PS/2 keyboard 1 x PS/2 mouse 1 x VGA 2 x USB - Type A 1 x RS-232 - DB-9
General
Depth	48.3 cm
Device Type	Network management device
Enclosure Color	Silver
Height	8.9 cm
Weight	25 kg
Width	71.1 cm
Manufacturer Warranty
Service & Support	Limited warranty - 2 years
Miscellaneous
Compliant Standards	RoHS, REACH SvHC, Mercury-free
Networking
Data Link Protocol	Ethernet, Fast Ethernet
Encryption Algorithm	SSL
Form Factor	Rack-mountable
Network / Transport Protocol	TCP/IP
Remote Management Protocol	SNMP, HTTP, HTTPS
Power
Power Device	Internal power supply
Processor / Memory / Storage
Hard Drive	HDD 300 GB x 5
RAID Level	RAID 5
RAM	4 GB
Software / System Requirements
Software Included	Drivers & Utilities
