Intel P5620 - SSD - Mixed Use
The Lenovo Intel P5620 solid state drive combines high-capacity storage, high performance, and advanced data protection to meet the needs of demanding applications and data security. With a 3.2 TB capacity, it offers ample space for all your storage needs. The drive's impressive speed, with an internal data rate of up to 6.7 GBps for reads and 3.6 GBps for writes, along with high IOPS, ensures swift data access and transfer, making it ideal for high-performance computing environments. Robust data protection features, including End-to-end data protection, Enhanced Power Loss Data Protection, and hardware encryption with Self-Encrypting Drive (SED) technology, provide peace of mind by securing your data against potential threats. Additionally, the drive's durability is underscored by its high MTBF of 2,000,000 hours and an SSD endurance of 17.5 PB, ensuring reliability and longevity. Efficient thermal management technologies, such as Thermal Monitoring and Thermal throttling, maintain optimal performance and prevent overheating, making the Lenovo Intel P5620 an excellent choice for professionals and enterprises seeking a high-performance, secure, and reliable storage solution.
| General Information | |
|---|---|
| Category | Hard drives |
| Description | Intel P5620 - SSD - Mixed Use - encrypted - 3.2 TB - internal - 2.5" - U.2 PCIe 4.0 x4 (NVMe) - Self-Encrypting Drive (SED), TCG Opal Encryption 2.01 - for ThinkSystem SD650-N V2 7D1N; SN550 V2 7Z69 |
| Manufacturer | Lenovo |
| MSRP | $1,589.00 |
| UNSPSC | 43201803 |
| Main Specifications | |
| Dimensions & Weight / Depth | 100 mm |
| Dimensions & Weight / Height | 15 mm |
| Dimensions & Weight / Weight | 146 g |
| Dimensions & Weight / Width | 70 mm |
| Hard Drive / Capacity | 3.2 TB |
| Hard Drive / Form Factor | 2.5" |
| Hard Drive / Hard Drive Type | Internal hard drive |
| Hard Drive / Interface | U.2 PCIe 4.0 x4 (NVMe) |
| Hard Drive / Interface | U.2 PCIe 4.0 x4 (NVMe) |
| Header / Brand | Intel |
| Miscellaneous / Product Color | Silver |
| Packaged Quantity | 1 |
| Service & Support / Type | 1-year warranty |
| Storage / Type | Solid state drive |
| Compatibility Information | |
| Designed For |
|
| Environmental Parameters | |
| Humidity Range Operating | 5 - 90% (non-condensing) |
| Max Operating Temperature | 70 °C |
| Min Operating Temperature | 0 °C |
| Shock Tolerance (operating) | 1000 g @ 0.5 ms |
| Vibration Tolerance (operating) | 2.17 gRMS @ 5-700 Hz |
| Expansion & Connectivity | |
| Compatible Bay | 2.5" |
| Interfaces | 1 x U.2 PCIe 4.0 x4 (NVMe) |
| General | |
| Capacity | 3.2 TB |
| Depth | 100 mm |
| Device Type | Solid state drive - internal |
| Features | Thermal Monitoring, Thermal throttling, 144-layer Intel 3D NAND TLC, Enhanced Power Loss Data Protection, End-to-end data protection, S.M.A.R.T. |
| Form Factor | 2.5" |
| Hardware Encryption | Yes |
| Height | 15 mm |
| Interface | U.2 PCIe 4.0 x4 (NVMe) |
| NAND Flash Memory Type | 3D triple-level cell (TLC) |
| Weight | 146 g |
| Width | 70 mm |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - replacement - 1 year |
| Miscellaneous | |
| Compliant Standards | FCC Part 15 Subpart B Class B, CAN/CSA-CEI/IEC CISPR 22:02, EN55024:1998, EN 55022:2006, EN 60950-1 Second Edition, UL/CSA EN-60950-1 2nd Edition, LVD 2006/95/EC, C-Tick AS/NZS3584, BSMI CNS 13438, KCC Article 11.1, RoHS 2011/65/EU, WEEE 2002/96/EC |
| Performance | |
| 4KB Random Read | 1000000 IOPS |
| 4KB Random Write | 341000 IOPS |
| Average Latency | 10 µs |
| Drive Class | Mixed Use |
| Drive Writes Per Day (DWPD) | 3 |
| Internal Data Rate | 6.7 GBps (read) / 3.6 GBps (write) |
| SSD Endurance | 17.5 PB |
| Power | |
| Power Consumption |
|
| Reliability | |
| MTBF | 2,000,000 hours |
| Non-Recoverable Errors | 1 per 10^17 |
| Software & System Requirements | |
| OS Required | Microsoft Windows Server 2016, Microsoft Windows Server 2019, Microsoft Windows Server 2022, Red Hat Enterprise Linux 7.6, Red Hat Enterprise Linux 7.7, Red Hat Enterprise Linux 7.8, Red Hat Enterprise Linux 7.9, Red Hat Enterprise Linux 8.0, Red Hat Enterprise Linux 8.1, Red Hat Enterprise Linux 8.3, Red Hat Enterprise Linux 8.4, Red Hat Enterprise Linux 8.5, Red Hat Enterprise Linux 8.6, SuSE Linux Enterprise Server 12 SP4, SUSE Linux Enterprise Server 12 SP5, SUSE Linux Enterprise Server 15 SP1, SUSE Linux Enterprise Server 15 SP2, SUSE Linux Enterprise Server 15 SP3, Ubuntu 18.04.5 LTS, Ubuntu 20.04 LTS, Ubuntu 22.04 LTS, VMware vSphere Hypervisor 6.5 (ESXi) Update 3, VMware vSphere Hypervisor 6.7 (ESXi) Update 3, VMware vSphere Hypervisor 7.0 (ESXi), VMware vSphere Hypervisor 7.0 (ESXi) Update 1, VMware vSphere Hypervisor 7.0 (ESXi) Update 2, VMware vSphere Hypervisor 7.0 (ESXi) Update 3 |
